Polaris RZR PRO R Service Manual page 322

FINAL DRIVE
14. Disconnect vent line and remove gearcase through
the opening in front of the frame.
15. Remove prop shaft through the opening in front of the
frame.
INSTALLATION
1. Install prop shaft through the front of vehicle.
2. Connect prop shaft slip yoke to the transmission
output shaft. On 4-seat vehicles, connect slip yoke to
intermediate output shaft.
NOTICE
The slip yoke on 4-seat vehicles has a skip-tooth. Align
skip tooth with the intermediate shaft to install.
8.22
3. Install front gearcase through the opening in front of
the frame. Connect vent line.
4. Install half shaft onto front gearcase input shaft.
5. Leave vertical bolts loosely installed.
6. Install two front gearcase isolator fasteners. Torque
fasteners to specification.
