Battery Life Advisory

The MVI46, MVI56, MVI56E, MVI69, and MVI71 modules use a rechargeable Lithium Vanadium Pentoxide battery to
backup the real-time clock and CMOS. The battery should last for the life of the module. The module must be
powered for approximately twenty hours before the battery becomes fully charged. After it is fully charged, the battery
provides backup power for the CMOS setup and the real-time clock for approximately 21 days. When the battery is
fully discharged, the module will revert to the default BIOS and clock settings.
Note: The battery is not user replaceable.

Markings

Electrical Ratings
Backplane Current Load: 800 mA @ 5.1 Vdc; 3 mA @ 24 Vdc
Operating Temperature: 0° C to 60° C (32° F to 140° F)
Storage Temperature: -40° C to 85° C (-40° F to 185° F)
Shock: 30 g, operational; 50 g, non-operational; Vibration: 5 g from 10 Hz to 150 Hz
Relative Humidity: 5% to 95% with no condensation
All phase conductor sizes must be at least 1.3 mm(squared) and all earth ground conductors must be at least
4mm(squared).
Label Markings
ATEX
II 3 G
EEx nA IIC T6
0° C <= Ta <= 60° C
cULus
E183151
Class I Div 2 Groups A,B,C,D
T6
-30° C <= Ta <= 60° C
Agency Approvals and Certifications
Agency
RoHS
CE
ATEX
cULus
CB Safety
GOST-R
CSA
Korea KCC
Applicable Standard
EMC-EN61326-1:2006; EN61000-6-4:2007
EN60079-15:2003
UL508; UL1604; CSA 22.2 No. 142 & 213
CA/10533/CSA
IEC 61010-1 Ed.2; CB 243333-2056722 (2090408)
EN 61010
EN 61010
KCC-REM-PFT-MVI56-AFC
243333
E183151
ME06
