Diagnostics and troubleshooting
Parameter
Actual diagnostics
Previous diagnostics
90
Parameter overview with brief description
Prerequisite
1 diagnostic event has
occurred.
2 diagnostic events have
already occurred.
12.7

Diagnostic list

In the Diagnostic list submenu, up to 5 currently pending diagnostic events can be
displayed along with the related diagnostic information. If more than 5 diagnostic events
are pending, the events with the highest priority are shown on the display.
Navigation path
Diagnostics menu → Diagnostic list submenu
To call up the measures to rectify a diagnostic event:
• Via Web browser
• Via "FieldCare" operating tool →  85
12.8

Event logbook

12.8.1

Event history

A chronological overview of the event messages that have occurred is provided in the
Events list submenu.
Navigation path
"Diagnostics" menu → Event logbook → Events list
The event history includes entries for:
• Diagnostic events →  86
• Information events →  91
In addition to the operation time of its occurrence, each event is also assigned a symbol
that indicates whether the event has occurred or is ended:
• Diagnostic event
• : Event has occurred
• : Event has ended
• Information event
: Event has occurred
To call up the measures to rectify a diagnostic event:
• Via Web browser
• Via "FieldCare" operating tool →  85
For filtering the displayed event messages →  91
Description
Displays the current diagnostic
event along with the
diagnostic information.

If two or more messages
occur simultaneously,
the message with the
highest priority is shown
on the display.
Displays the diagnostic event
that occurred prior to the
current diagnostic event along
with the diagnostic
information.
Proline Cubemass C 100 HART
User interface Factory setting
Symbol for diagnostic –
behavior, diagnostic
code and short
message.
Symbol for diagnostic –
behavior, diagnostic
code and short
message.
