Commissioning
Parameter
Assign current output
Mass flow unit
Volume flow unit
Current span
0/4 mA value
20 mA value
Failure mode
Failure current
58
Parameter overview with brief description
Description
Select process variable for current output.
Select mass flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select volume flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select current range for process value output
and upper/lower level for alarm signal.
Enter 4 mA value.
Enter 20 mA value.
Define output behavior in alarm condition.
Enter current output value in alarm
condition.
Proline Cubemass C 100 HART
Selection / User entry
• Off
• Mass flow
• Volume flow
• Corrected volume flow
• Target mass flow
• Carrier mass flow
• Density
• Reference density
• Concentration
• Dynamic viscosity
• Kinematic viscosity
• Temp. compensated
dynamic viscosity
• Temp. compensated
kinematic viscosity
• Temperature
• Carrier pipe temperature
• Electronic temperature
• Oscillation frequency 0
• Oscillation frequency 1
• Oscillation amplitude 0
• Oscillation amplitude 1
• Frequency fluctuation 0
• Frequency fluctuation 1
• Oscillation damping 0
• Oscillation damping 1
• Tube damping fluctuation 0
• Tube damping fluctuation 1
• Signal asymmetry
• Exciter current 0
• Exciter current 1
• Sensor integrity
Unit choose list
Unit choose list
• 4...20 mA NAMUR
• 4...20 mA US
• 4...20 mA
• 0...20 mA
• Fixed current
Signed floating-point number
Signed floating-point number
• Min.
• Max.
• Last valid value
• Actual value
• Defined value
-3 -3
3.59 · 10 to 22.5 · 10 mA
Factory setting
Mass flow
Country-specific:
• kg/h
• lb/min
Country-specific:
• l/h
• gal/min (us)
4...20 mA NAMUR
0 kg/h
2.5 kg/h
Max.
22.5 mA
