Commissioning
Parameter
Operating mode
Switch output function
Assign diagnostic behavior
Assign limit
Assign flow direction check
Assign status
Mass flow unit
Volume flow unit
Unit totalizer
Switch-on value
Switch-off value
Switch-on delay
62
Parameter overview with brief description
Description
Define the output as a pulse, frequency or
switch output.
Select function for switch output.
Select diagnostic behavior for switch output.
Select process variable for limit function.
Select process variable for flow direction
monitoring.
Select device status for switch output.
Select mass flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select volume flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select process variable totalizer unit.
Enter measured value for the switch-on
point.
Enter measured value for the switch-off
point.
Define delay for the switch-on of status
output.
Proline Cubemass C 100 HART
Selection / User entry
• Pulse
• Frequency
• Switch
• Off
• On
• Diagnostic behavior
• Limit
• Flow direction check
• Status
• Alarm
• Alarm or warning
• Warning
• Mass flow
• Volume flow
• Corrected volume flow
• Target mass flow
• Carrier mass flow
• Density
• Reference density
• Dynamic viscosity
• Concentration
• Kinematic viscosity
• Temp. compensated
dynamic viscosity
• Temp. compensated
kinematic viscosity
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Measuring tube damping
• Off
• Volume flow
• Mass flow
• Corrected volume flow
• Partially filled pipe detection
• Low flow cut off
Unit choose list
Unit choose list
Unit choose list
Signed floating-point number
Signed floating-point number
0.0 to 100.0 s
Factory setting
Pulse
Off
Alarm
Mass flow
Mass flow
Partially filled pipe detection
Country-specific:
• kg/h
• lb/min
Country-specific:
• l/h
• gal/min (us)
kg
0 kg/h
0 kg/h
0.0 s
