Simulation - Endress+Hauser Proline Cubemass C 100 HART Operating Instructions Manual

Proline Cubemass C 100 HART
Parameter
Decimal places 3
Value 4 display
Decimal places 4
Display language
Display interval
Display damping
Header
Header text
Separator
Backlight
Endress+Hauser
Description
Select the number of decimal places for the
display value.
Select the measured value that is shown on
the local display.
Select the number of decimal places for the
display value.
Set display language.
Set time measured values are shown on
display if display alternates between values.
Set display reaction time to fluctuations in
the measured value.
Select header contents on local display.
Enter display header text.
Select decimal separator for displaying
numerical values.
Switch the local display backlight on and off. • Disable
10.4

Simulation

The "Simulation" submenu enables you to simulate, without a real flow situation, various
process variables in the process and the device alarm mode and to verify downstream
signal chains (switching valves or closed-control loops).
Navigation
"Diagnostics" menu → Simulation
Simulation
Selection / User entry
• x
• x.x
• x.xx
• x.xxx
• x.xxxx
Picklist (see 1st display value)
• x
• x.x
• x.xx
• x.xxx
• x.xxxx
• English
• Deutsch
• Français
• Español
• Italiano
• Nederlands
• Portuguesa
• Polski
• русский язык (Russian)
• Svenska
• Türkçe
• 中文 (Chinese)
• 日本語 (Japanese)
• 한국어 (Korean)
• ‫( ا ل ْ ع َ ر َب ي ّة‬Arabic)
• Bahasa Indonesia
• ภาษาไทย (Thai)
• tiếng Việt (Vietnamese)
• čeština (Czech)
1 to 10 s
0.0 to 999.9 s
• Device tag
• Free text
• .
• ,
• Enable
→ Assign simulation process variable
Value process variable
Simulation current output
Commissioning
Factory setting
x.xx
None
x.xx
English (alternatively, the
ordered language is preset in
the device)
5 s
0.0 s
Device tag
------------
.
Enable
75
