Proline Cubemass C 100 HART
Parameter
Corrected volume flow calculation
External reference density
Fixed reference density
Reference temperature
Linear expansion coefficient
Square expansion coefficient
Endress+Hauser
Parameter overview with brief description
Prerequisite
–
–
The following option is
selected in the Corrected
volume flow calculation
parameter:
Fixed reference density
The following option is
selected in the Corrected
volume flow calculation
parameter:
Calculated reference density
The following option is
selected in the Corrected
volume flow calculation
parameter:
Calculated reference density
–
10.3.2

Carrying out a sensor adjustment

The Sensor adjustment submenu contains parameters that pertain to the functionality of
the sensor.
Navigation
"Setup" menu → Advanced setup → Sensor adjustment
Structure of the submenu
Sensor adjustment
Description
Select reference density for
calculating the corrected
volume flow.
Shows external reference
density.
Enter fixed value for reference
density.
Enter reference temperature
for calculating the reference
density.
Enter linear, medium-specific
expansion coefficient for
calculating the reference
density.
For media with a non-linear
expansion pattern: enter the
quadratic, medium-specific
expansion coefficient for
calculating the reference
density.
→ Installation direction
Zero point adjustment
Commissioning
Selection / User Factory setting
entry
• Fixed reference Calculated reference
density density
• Calculated
reference density
• Reference density
by API table 53
Floating point 0 kg/Nl
number with sign
Positive floating- 1 kg/Nl
point number
–273.15 to 99 999 °C 20 °C
Signed floating-point 0.0
number
Signed floating-point 0.0
number
→
→
Zero point adjustment control
Progress
