Technical data
Response time
Influence of ambient
temperature
Influence of medium
temperature
Influence of medium
pressure
108
The response time depends on the configuration (damping).
Current output
o.r. = of reading
Temperature coefficient Max. ±0.005 % o.r./°C
Pulse/frequency output
Temperature coefficient No additional effect. Included in accuracy.
Mass flow and volume flow
o.f.s. = of full scale value
When there is a difference between the temperature for zero point adjustment and the
process temperature, the additional measured error of the sensor is typically ±0.0002 %
o.f.s./°C (±0.0001 % o. f.s./°F).
The effect is reduced if zero point adjustment is performed at process temperature.
Density
When there is a difference between the density calibration temperature and the process
temperature, the typical measured error of the sensor is
±0.00005 g/cm 3 /°C (±0.000025 g/cm
Wide-range density specification (special density calibration)
If the process temperature is outside the valid range (→  106) the measured error is
±0.00005 g/cm 3 /°C (±0.000025 g/cm
3
[kg/m ]
10
8
6
4
2
0
-50
-80 -40 0
1 Field density calibration, for example at +20 °C (+68 °F)
2 Special density calibration
Temperature
±0.005 · T °C (± 0.005 · (T – 32) °F)
The table below shows the effect on accuracy of mass flow due to a difference between
calibration pressure and process pressure.
3 /°F). Field density calibration is possible.
3 /°F)
0 50 100
40 80 120 160 200 240 280 320 360 400
Proline Cubemass C 100 HART
1
2
[°C]
150 200
[°F]
Endress+Hauser
A0016617
