Commissioning
Parameter
Installation direction
Zero point adjustment control
Progress
Parameter
Assign process variable
Unit totalizer
Totalizer operation mode
Failure mode
72
Parameter overview with brief description
Description
Set sign of flow direction to match the
direction of the arrow on the sensor.
Start zero point adjustment.
Shows the progress of the process.
10.3.3

Configuring the totalizer

In the "Totalizer 1 to n" submenu the individual totalizers can be configured.
Navigation
"Setup" menu → Advanced setup → Totalizer 1 to n
Totalizer 1 to n
Parameter overview with brief description
Description
Select process variable for totalizer.
Select process variable totalizer unit.
Select totalizer calculation mode.
Define totalizer behavior in alarm condition.
Proline Cubemass C 100 HART
Selection / User interface
• Flow in arrow direction
• Flow against arrow direction
• Cancel
• Busy
• Zero point adjust failure
• Start
0 to 100 %
→ Assign process variable
Unit totalizer
Failure mode
Selection
• Off
• Volume flow
• Mass flow
• Corrected volume flow
• Target mass flow
• Carrier mass flow
Unit choose list
• Net flow total
• Forward flow total
• Reverse flow total
• Stop
• Actual value
• Last valid value
Factory setting
Flow in arrow direction
Cancel
0 %
Factory setting
Mass flow
kg
Net flow total
Stop
