Supply voltage
Power consumption
Current consumption
Power supply failure
Electrical connection
Potential equalization
Terminals
Cable entries
Cable specification
Endress+Hauser
Protocol-specific data
• For information on the device description files
• For information on the dynamic variables and measured variables (HART device
variables) →  48
16.5

Power supply

→  27
→  28
The power unit must be tested to ensure it meets safety requirements (e.g. PELV, SELV).
Transmitter
DC 20 to 30 V
Transmitter
Order code for "Output"
Option B: 4-20 mA HART with pulse/frequency/switch output
Transmitter
Order code for "Output"
Option B: 4-20mA HART, pul./freq./switch output
• Totalizers stop at the last value measured.
• Depending on the device version, the configuration is retained in the device memoryor in
the pluggable data memory (HistoROM DAT).
• Error messages (incl. total operated hours) are stored.
→  28
→  30
Transmitter
Spring terminals for wire cross-sections0.5 to 2.5 mm
• Cable gland: M20 × 1.5 with cable Ø 6 to 12 mm (0.24 to 0.47 in)
• Thread for cable entry:
• M20
• G ½"
• NPT ½"
→  26
Maximum
Power consumption
Maximum
Current consumption switch-on current
145 mA 18 A (< 0.125 ms)
2 (20 to 14 AWG)
Technical data
3.5 W
Maximum
