Proline Cubemass C 100 HART
Parameter
Mass flow unit
Volume flow unit
Minimum frequency value
Maximum frequency value
Measuring value at minimum
frequency
Measuring value at maximum
frequency
Failure mode
Failure frequency
Invert output signal
Endress+Hauser
Description
Select mass flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select volume flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Enter minimum frequency.
Enter maximum frequency.
Enter measured value for minmum
frequency.
Enter measured value for maximum
frequency.
Define output behavior in alarm condition.
Enter frequency output value in alarm
condition.
Invert the output signal.
Switch output
Navigation
"Setup" menu → Pulse/frequency/switch output
Structure of the submenu for the switch output
Pulse/frequency/switch output
Selection / User entry
Unit choose list
Unit choose list
0.0 to 10 000.0 Hz
0.0 to 10 000.0 Hz
Signed floating-point number
Signed floating-point number
• Actual value
• Defined value
• 0 Hz
0.0 to 12 500.0 Hz
• No
• Yes
→ Operating mode
Switch output function
Assign diagnostic behavior
Assign limit
Assign flow direction check
Assign status
Switch-on value
Switch-off value
Failure mode
Invert output signal
Commissioning
Factory setting
Country-specific:
• kg/h
• lb/min
Country-specific:
• l/h
• gal/min (us)
0.0 Hz
10 000.0 Hz
0
0
0 Hz
0.0 Hz
No
