Proline Cubemass C 100 HART
Endress+Hauser
3
Product description
The device consists of a transmitter and a sensor.
The device is available as a compact version:
The transmitter and sensor form a mechanical unit.
3.1
Product design
3.1.1
Device version with HART communication protocol
4
3
2
1
1
Important components of a measuring device
1
Sensor
2
Transmitter housing
3
Main electronics module
4
Transmitter housing cover
5
Transmitter housing cover (version for optional local display)
6
Local display (optional)
7
Main electronics module (with bracket for optional local display)
Product description
5
6
7
A0023153
11
