Technical data
Remote operation
Service interface
116
For some work performed on the measuring device (e.g. electrical connection), it is
advisable to disconnect the local display from the main electronics module:
1. Press in the side latches of the local display.
2. Remove the local display from the main electronics module. Pay attention to the
length of the connecting cable when doing so.
Once the work is completed, plug the local display back on.
Via HART protocol
This communication interface is available in device versions with a HART output.
1
 22 Options for remote operation via HART protocol
1 Control system (e.g. PLC)
2 Field Communicator 475
3 Computer with operating tool (e.g. FieldCare, AMS Device Manager, SIMATIC PDM)
4 Commubox FXA195 (USB)
5 Field Xpert SFX350 or SFX370
6 Field Xpert SMT70
7 VIATOR Bluetooth modem with connecting cable
8 Transmitter
Via service interface (CDI-RJ45)
4
2 3
Proline Cubemass C 100 HART
8
7
5 6
Endress+Hauser
A0028747
