Technical data
114
Order code for "Housing", option A "Compact, aluminum, coated"
The various cable entries are suitable for hazardous and non-hazardous areas.
Cable entry/cable gland
Cable gland M20 × 1.5
Adapter for cable entry with female thread G ½"
Adapter for cable entry with female thread NPT ½"
Order code for "Housing", option B "Compact, hygienic, stainless"
The various cable entries are suitable for hazardous and non-hazardous areas.
Cable entry/cable gland
Cable gland M20 × 1.5
Adapter for cable entry with female thread G ½"
Adapter for cable entry with female thread NPT ½"
Device plug
Electrical connection
Plug M12x1
Sensor housing
• Acid and alkali-resistant outer surface
• Stainless steel 1.4301 (304)
Measuring tubes
Stainless steel, 1.4539 (904L)
Process connections
VCO connection:
VCO connection: stainless steel, 1.4539 (904L)
Adapter for DN 15 flange according to EN 1092-1 (DIN2501) / according to ASME B
16.5 / as per JIS B2220:
Stainless steel, 1.4539 (904L)
NPTF adapter:
Stainless steel, 1.4539 (904L)
Available process connections→  115
Seals
Welded process connections without internal seals
Seals for mounting kit
• Viton
• EPDM
• Silicone
• Kalrez
Proline Cubemass C 100 HART
Material
Nickel-plated brass
Material
Stainless steel, 1.4404 (316L)
Material
• Socket: Stainless steel, 1.4404 (316L)
• Contact housing: Polyamide
• Contacts: Gold-plated brass
