Diagnostics and troubleshooting
86
You can assign the following options to the diagnostic number as the diagnostic behavior:
Options Description
Alarm Measurement is interrupted. Signal outputs and totalizers assume the defined alarm
condition. A diagnostic message is generated.
Warning Measurement is resumed. The signal outputs and totalizers are not affected. A
diagnostic message is generated.
Logbook entry only The device continues to measure. The diagnostic message is entered in the Event
logbook (events list) submenu only and is not displayed in alternation with the measured
value display.
Off The diagnostic event is ignored, and no diagnostic message is generated or entered.
12.4.2

Adapting the status signal

Each item of diagnostic information is assigned a specific status signal at the factory. The
user can change this assignment for certain diagnostic information in the Diagnostic
event category submenu .
Expert → Communication → Diagnostic event category
Available status signals
Configuration as per HART 7 Specification (Condensed Status), in accordance with
NAMUR NE107.
Symbol Meaning
Failure
A device error has occurred. The measured value is no longer valid.
A0013956
Function check
The device is in service mode (e.g. during a simulation).
A0013959
Out of specification
The device is being operated:
• Outside its technical specification limits (e.g. outside the process temperature range)
• Outside of the configuration carried out by the user (e.g. maximum flow in parameter
A0013958
20 mA value)
Maintenance required
Maintenance is required. The measured value is still valid.
A0013957
Has no effect on the condensed status.
A0023076
12.5

Overview of diagnostic information

In the case of some items of diagnostic information, the status signal and the
diagnostic behavior can be changed. Adapt the diagnostic information →  85
Diagnostic Short text
number
Diagnostic of sensor
022 Sensor temperature
046 Sensor limit exceeded
Proline Cubemass C 100 HART
Remedy instructions
1. Change main electronic
module
2. Change sensor
1. Inspect sensor
2. Check process condition
Status Diagnostic
signal behavior
[from the [from the
factory] factory]
F Alarm
S Alarm
