Proline Cubemass C 100 HART
Parameter
Pulse value 1
Switch output simulation 1
Switch status 1
Simulation device alarm
Simulation diagnostic event
Endress+Hauser
Prerequisite
The Down-count. val. option
is selected in the Simulation
pulse output parameter.
–
The On option is selected in
the Switch output simulation
parameter.
–
–
10.5 Protecting settings from unauthorized access
The following options exist for protecting the configuration of the measuring device from
unintentional modification after commissioning:
• Write protection via access code for Web browser →  77
• Write protection via write protection switch →  78
10.5.1

Write protection via access code

With the customer-specific access code, access to the measuring device via the Web
browser is protected, as are the parameters for the measuring device configuration.
Navigation
"Setup" menu → Advanced setup → Administration → Define access code
Structure of the submenu
Define access code
Defining the access code via the Web browser
1. Navigate to the Enter access code parameter.
2. Define a max. 4-digit numeric code as an access code.
3. Enter the access code again to confirm the code.
 The Web browser switches to the login page.
If no action is performed for 10 minutes, the Web browser automatically returns to
the login page.
The user role with which the user is currently logged on via the Web browser is
indicated by the Access status tooling parameter. Navigation path: Operation →
Access status tooling
Description
Enter the number of pulses for
simulation.
Switch simulation of switch
output on and off.
Select the status of the status
output for the simulation.
Switch the device alarm on and
off.
Switch simulation of the
diagnostic event on and off.
For the simulation, you can
choose from the diagnostic
events of the category selected
in the Diagnostic event
category parameter.
→ Define access code
Confirm access code
Commissioning
Selection / User Factory setting
entry
0 to 65 535 0
• Off Off
• On
• Open Open
• Closed
• Off Off
• On
• Off Off
• Picklist
Diagnostic events
(depends on the
selected category)
77
