Diagnostics and troubleshooting

12.1

General troubleshooting

For output signals
Problem
Green power LED on the main
electronics module of the
transmitter is dark
Device measures incorrectly.
For access
Problem
No write access to parameters
No connection via HART protocol
No connection via HART protocol
Not connecting to Web server
Not connecting to Web server
No or incomplete display of
contents in the Web browser
Web browser frozen and operation
no longer possible
Web browser frozen and operation
no longer possible
Content of Web browser
incomplete or difficult to read
Content of Web browser
incomplete or difficult to read
Possible causes
Supply voltage does not match that
specified on the nameplate.
Configuration error or device is
operated outside the application.
Possible causes
Hardware write protection enabled
Missing or incorrectly installed
communication resistor.
Commubox
• Connected incorrectly
• Configured incorrectly
• Drivers not installed correctly
• USB interface on computer
configured incorrectly
Incorrect setting for the Ethernet
interface of the computer
Web server disabled
• JavaScript not enabled
• JavaScript cannot be enabled
Data transfer active
Connection lost
Not using optimum version of Web
server.
Unsuitable view settings.
Diagnostics and troubleshooting
Remedy
Apply the correct supply voltage
→  29.
1. Check and correct parameter
configuration.
2. Observe limit values specified in
the "Technical Data".
Remedy
Set the write protection switch on
the main electronics module to the
OFF position →  78.
Install the communication resistor
(250 Ω) correctly. Observe the
maximum load .
Observe the documentation for the
Commubox.

FXA195 HART: Document
"Technical Information"
TI00404F
1. Check the properties of the
Internet protocol (TCP/IP) .
2. Check the network settings with
the IT manager.
Via the "FieldCare" operating tool
check whether the Web server of
the measuring device is enabled
and enable it if necessary →  43.
1. Enable JavaScript.
2. Enter http://XXX.XXX.X.XXX/
basic.html as the IP address.
Wait until data transfer or current
action is finished.
1. Check cable connection and
power supply.
2. Refresh the Web browser and
restart if necessary.
1. Use the correct Web browser
version .
2. Clear the Web browser cache and
restart the Web browser.
Change the font size/display ratio
of the Web browser.
