Proline Cubemass C 100 HART
Parameter
Mass flow
Volume flow
Corrected volume flow
Endress+Hauser
11

Operation

11.1

Reading device locking status

The write protection types that are currently active can be determined using the Locking
status parameter.
Navigation
"Operation" menu → Locking status
Function scope of "Locking status" parameter
Options Description
Hardware locked The locking switch (DIPswitch) for locking the hardware is activated on the main
electronic module. This prevents write access to the parameters →  78.
Temporarily locked Due to internal processing in the device (e.g. up-/downloading of data, reset), write
access to the parameters is blocked for a short time. Once the internal processing
has been completed, the parameters can be changed once again.
11.2

Reading measured values

Using the Measured values submenu , it is possible to read all the measured values.
Diagnostics → Measured values
11.2.1

Process variables

The Process variables submenu contains all the parameters needed to display the current
measured values for every process variable.
Navigation
"Diagnostics" menu → Measured values → Process variables
Process variables
Parameter overview with brief description
Description
Displays the mass flow currently measured.
Displays the calculated volume flow.
Displays the corrected volume flow currently
calculated.
Mass flow
Volume flow
Corrected volume flow
Density
Reference density
Temperature
Pressure value
User interface
Signed floating-point number
Signed floating-point number
Signed floating-point number
Operation
Factory setting
–
–
–
79
