16.12 Certificates And Approvals - Endress+Hauser Proline Cubemass C 100 HART Operating Instructions Manual

Proline Cubemass C 100 HART
Languages
CE mark
RCM-tick symbol
Ex approval
HART certification
Endress+Hauser
HART
2
3
 23 Connection for the order code for "Output", option B: 4-20 mA HART, pulse/frequency/switch output
1 Service interface (CDI -RJ45) of the measuring device with access to the integrated Web server
2 Computer with Web browser (e.g. Internet Explorer) for accessing the integrated device Web server or with
"FieldCare" operating tool with COM DTM "CDI Communication TCP/IP"
3 Standard Ethernet connecting cable with RJ45 plug
Can be operated in the following languages:
• Via "FieldCare" operating tool: English, German, French, Spanish, Italian, Chinese,
Japanese
• Via Web browser
English, German, French, Spanish, Italian, Dutch, Portuguese, Polish, Russian, Turkish,
Chinese, Japanese, Bahasa (Indonesian), Vietnamese, Czech, Swedish, Korean

16.12 Certificates and approvals

Currently available certificates and approvals can be called up via the product
configurator.
The device meets the legal requirements of the applicable EU Directives. These are listed in
the corresponding EU Declaration of Conformity along with the standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
The measuring system meets the EMC requirements of the "Australian Communications
and Media Authority (ACMA)".
The devices are certified for use in hazardous areas and the relevant safety instructions are
provided in the separate "Safety Instructions" (XA) document. Reference is made to this
document on the nameplate.
HART interface
The measuring device is certified and registered by the FieldComm Group. The measuring
system meets all the requirements of the following specifications:
• Certified according to HART 7
• The device can also be operated with certified devices of other manufacturers
(interoperability)
Technical data
1
A0016926
117
