Operation
Parameter
Density
Reference density
Temperature
Pressure value
Parameter
Totalizer value 1 to n
Totalizer overflow 1 to n
80
Description
Displays the density currently measured.
Displays the reference density currently
calculated.
Displays the temperature currently
measured.
Displays either a fixed or external pressure
value.
11.2.2

Totalizer

The "Totalizer" submenu contains all the parameters needed to display the current
measured values for every totalizer.
Navigation
"Diagnostics" menu → Measured values → Totalizer
Structure of the submenu
Totalizer
Parameter overview with brief description
Prerequisite
In the Assign process variable
parameter of Totalizer 1 to n
submenu one of the following
options is selected:
• Volume flow
• Mass flow
• Corrected volume flow
In the Assign process variable
parameter of Totalizer 1 to n
submenu one of the following
options is selected:
• Volume flow
• Mass flow
• Corrected volume flow
11.2.3

Output values

The "Output values" submenu contains all the parameters needed to display the current
measured values for every output.
Navigation
"Diagnostics" menu → Measured values → Output values
Structure of the submenu
Output values
User interface
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
→ Totalizer value
Totalizer overflow
Description
Displays the current totalizer
counter value.
Displays the current totalizer
overflow.
→ Output current 1
Measured current 1
Proline Cubemass C 100 HART
Factory setting
–
–
User interface Factory setting
Signed floating-point 0 kg
number
– 0
32 000.0 to 32 000.0
