Proline Cubemass C 100 HART
Parameter
Output current 1
Measured current 1
Pulse output 1
Output frequency 1
Switch status 1
Endress+Hauser
Parameter overview with brief description
Description
Displays the current value currently
calculated for the current output.
Displays the current value currently
measured for the current output.
Displays the value currently measured for
the pulse output.
Displays the value currently measured for
the frequency output.
Displays the current switch output status.
11.3

Adapting the measuring device to the process

conditions

The following are available for this purpose:
• Basic settings using the Setup menu →  53
• Advanced settings using the Advanced setup submenu →  70
11.4

Performing a totalizer reset

In the Operation submenu the totalizers are reset:
• Control Totalizer
• Reset all totalizers
Function scope of "Control Totalizer " parameter
Options Description
Totalize The totalizer is started.
Stop Totalizing is stopped.
Reset + hold The totaling process is stopped and the totalizer is reset to 0.
Preset + hold The totaling process is stopped and the totalizer is set to its defined start value
from the Preset value parameter.
Reset + totalize The totalizer is reset to 0 and the totaling process is restarted.
Preset + totalize The totalizer is set to the defined start value in Preset value parameterand the
totaling process is restarted.
Function scope of "Reset all totalizers" parameter
Options Description
Reset + totalize Resets all totalizers to 0 and restarts the totaling process. This deletes all the flow
values previously totalized.
Pulse output 1
Output frequency 1
Switch status 1
User interface
3.59 to 22.5 mA
0 to 30 mA
Positive floating-point number
0.0 to 12 500.0 Hz
• Open
• Closed
Operation
Factory setting
3.59 mA
0 mA
0 Hz
0.0 Hz
Open
81
