Performance Characteristics - Endress+Hauser Proline Cubemass C 100 HART Operating Instructions Manual

Technical data
Reference operating
conditions
Maximum measured error
106
16.6

Performance characteristics

• Error limits based on ISO 11631
• Water with +15 to +45 °C (+59 to +113 °F) at2 to 6 bar (29 to 87 psi)
• Specifications as per calibration protocol
• Accuracy based on accredited calibration rigs that are traced to ISO 17025.
To obtain measured errors, use the Applicator sizing tool →  99
o.r. = of reading; 1 g/cm³ = 1 kg/l; T = medium temperature
Base accuracy
Design fundamentals →  109
Mass flow and volume flow (liquids)
±0.10 % o.r.
Mass flow (gases)
±0.50 % o.r.
Density (liquids)
Under reference conditions
[g/cm³]
±0.0005
1) Valid over the entire temperature and density range
2) Valid range for special density calibration: 0 to 2 g/cm³, +5 to +80 °C (+41 to +176 °F)
3) Order code for "Application package", option EE "Special density"
Temperature
±0.5 °C ± 0.005 · T °C (±0.9 °F ± 0.003 · (T – 32) °F)
Zero point stability
DN
[mm]
1
2
4
6
Flow values
Flow values as turndown parameter depending on nominal diameter.
1)
Standard density calibration
[g/cm³]
±0.02
[in] [kg/h]
¹⁄₂₄ 0.0008
¹⁄₁₂ 0.002
¹⁄₈ 0.014
¹⁄₄ 0.02
Proline Cubemass C 100 HART
Wide-range
2) 3)
Density specification
[g/cm³]
±0.002
Zero point stability
[lb/min]
0.00003
0.00007
0.0005
0.0007
Endress+Hauser
