Diagnostics and troubleshooting
88
Diagnostic Short text
number
Diagnostic of configuration
410 Data transfer
411 Up-/download active
431 Trim 1
437 Configuration
incompatible
438 Dataset
441 Current output 1
442 Frequency output
443 Pulse output
453 Flow override
484 Simulation failure mode
485 Simulation measured
variable
491 Simulation current output
1
492 Simulation frequency
output
493 Simulation pulse output
494 Switch output simulation
495 Simulation diagnostic
event
537 Configuration
590 Special event 3
591 Special event 7
592 Special event 11
Diagnostic of process
803 Current loop
830 Sensor temperature too
high
831 Sensor temperature too
low
832 Electronic temperature
too high
833 Electronic temperature
too low
Proline Cubemass C 100 HART
Remedy instructions
1. Check connection
2. Retry data transfer
Up-/download active, please wait C
Carry out trim
1. Restart device
2. Contact service
1. Check data set file
2. Check device configuration
3. Up- and download new
configuration
1. Check process
2. Check current output settings
1. Check process
2. Check frequency output
settings
1. Check process
2. Check pulse output settings
Deactivate flow override
Deactivate simulation
Deactivate simulation
Deactivate simulation
Deactivate simulation frequency
output
Deactivate simulation pulse
output
Deactivate simulation switch
output
Deactivate simulation
1. Check IP addresses in network
2. Change IP address
Contact service
Contact service
Contact service
1. Check wiring
2. Change I/O module
Reduce ambient temp. around the
sensor housing
Increase ambient temp. around
the sensor housing
Reduce ambient temperature
Increase ambient temperature
Status Diagnostic
signal behavior
[from the [from the
factory] factory]
F Alarm
Warning
C Warning
F Alarm
M Warning
1)
S Warning
1)
S Warning
1)
S Warning
C Warning
C Alarm
C Warning
C Warning
C Warning
C Warning
C Warning
C Warning
F Warning
F Alarm
F Alarm
1)
F Alarm
F Alarm
S Warning
S Warning
1)
S Warning
1)
S Warning
