Proline Cubemass C 100 HART
Signal on alarm
Endress+Hauser
Pulse value
Assignable measured
variables
Frequency output
Output frequency
Damping
Pulse/pause ratio
Assignable measured
variables
Switch output
Switching behavior
Switching delay
Number of switching
cycles
Assignable functions
Depending on the interface, failure information is displayed as follows:
Current output 4 to 20 mA
4 to 20 mA
Failure mode
Adjustable
• Mass flow
• Volume flow
• Corrected volume flow
Adjustable: 0 to 12 500 Hz
Adjustable: 0 to 999 s
1:1
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature

The range of options increases if the measuring device has one or more
application packages.
Binary, conductive or non-conductive
Adjustable: 0 to 100 s
Unlimited
• Off
• On
• Diagnostic behavior
• Limit value
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
• Totalizer 1-3
• Flow direction monitoring
• Status
• Partially filled pipe detection
• Low flow cut off

The range of options increases if the measuring device has one or more
application packages.
Choose from:
• 4 to 20 mA in accordance with NAMUR recommendation NE 43
• 4 to 20 mA in accordance with US
• Min. value: 3.59 mA
• Max. value: 22.5 mA
• Freely definable value between: 3.59 to 22.5 mA
• Actual value
• Last valid value
Technical data
