16.12 Certificates And Approvals - Endress+Hauser Proline Prosonic Flow W 400 Operating Instructions Manual

Technical data
There are different types of data storage units in which device data are stored and used by the device:
HistoROM backup
Available data • Event logbook, e.g. diagnostic
events
• Device firmware package
Storage location Fixed on the user interface PC
board in the connection
compartment
168
Additional information on the data storage concept
T-DAT
• Measured value logging ("Extended HistoROM"
order option)
• Current parameter data record (used by
firmware at run time)
• Indicator (minimum/maximum values)
• Totalizer value
Can be plugged into the user interface PC board in
the connection compartment
Data backup
Automatically
• The most important device data (sensor and transmitter) are automatically saved in the
DAT modules.
• If the transmitter or measuring device is replaced: Once the T-DAT containing the
previous device data has been exchanged, the new measuring device goes into operation
immediately, without any errors.
• If the sensor is replaced: Once the S-DAT has been replaced with new device data, the
measuring device goes into operation immediately, without any errors.
Data transmission
Manual
Transfer of a device configuration to another device using the export function of the
specific operating tool, e.g. with FieldCare, DeviceCare or Web server: to duplicate the
configuration or to store in an archive (e.g. for backup purposes)
Event list
Automatic
• Chronological display of up to 20 event messages in the events list
• If the Extended HistoROM application package (order option) is enabled: up to 100
event messages are displayed in the events list along with a time stamp, plain text
description and remedial measures
• The events list can be exported and displayed via a variety of interfaces and operating
tools e.g. DeviceCare, FieldCare or Web server
Data logging
Manual
If the Extended HistoROM application package (order option) is enabled:
• Recording of 1 to 4 channels of up to 1 000 measured values (up to 250 measured values
per channel)
• User configurable recording interval
• Export the measured value log via a variety of interfaces and operating tools e.g.
FieldCare, DeviceCare or web server

16.12 Certificates and approvals

Current certificates and approvals for the product are available at
relevant product page:
1. Select the product using the filters and search field.
2. Open the product page.
Proline Prosonic Flow W 400 HART
S-DAT
• Sensor data: e.g.
• Serial number
• Device configuration (e.g. SW options,
fixed I/O or multi I/O)
Fixed on the sensor connection board
www.endress.com
Endress+Hauser
on the
