To pan, or move backward and forward in
l
time, touch and drag (swipe) left and right
on each graph.
To zoom in on a specific point in time,
l
double tap the point on the graph. The
view zooms in 2x (or displays half the
amount of time) for each double tap.
To zoom in or out, decreasing or increasing
l
the time interval displayed, drag the slider
or tap the slider bar below the graphs.
⸰ The largest time interval (maximum
zoom out) is the total time data has
accumulated.
To reset the graph to the default time
l
interval, tap the zoom reset icon
⸰ The zoom reset icon appears once you
have zoomed or panned on the graph.
⸰ The default time interval varies across
different apps.
The following apps and screens contain
trending graphs:
