To pan and zoom on the graphs, you can
swipe, double tap, and move the slider. See the
Trending Graphs
graph controls.
Device Name: Hostname or address of the iPerf
server or Test Accessory
IP Address: IPv4 address of the iPerf server
Interface: The EtherScope Test or Management
Port from which the test is running
Results
Duration: Configured Duration from the
l
iPerf settings
Started: Time the test started
l
Status: Success or failure status of the test
l
TCP/UDP Throughput Up and Down graphs:
The iPerf graphs plot the throughput rate to
(Up) or from (Down) the iPerf server in Mbps.
The table below each graph displays the
Current, Minimum, Maximum, and Average
rates.
topic for an overview of the
726
iPerf Test App
