or 10G.
To pan and zoom on the graphs, you
l
can swipe, double tap, and move the
slider. See the
for an overview of the graph controls.
5. Let the test run to completion. The Status
shows the test result (Success or Failure)
and may display additional information,
such as not connecting at the fastest
advertised speed.
About LANBERT Results
The color of the LANBERT icon indicates
l
success or failure (green for success, red for
failure).
The first line below the icon displays
l
information about the connection
including:
Connector type
l
Speed (in bold). Other speeds shown as
l
grayed out values are the ones that were
advertised by the link partner but not
Trending Graphs
741
LANBERT™ Test App
topic
