you run a Ping or TCP Connect test, using the
Ping/TCP
connection while the Profile is linked.
Follow these steps to view the Response Time
graph:
1. To navigate easily to the Ping/TCP app,
touch the blue
bottom of the Link test screen.
The Ping/TCP app opens with the Interface
set to Wi-Fi Port and Protocol set to Ping.
2. Access and adjust the Ping/TCP settings as
desired.
3. START the Ping or TCP Connect test.
4. Touch back
Wi-Fi Link screen.
The Response Time graph appears near the
bottom of the screen and updates in real
time along with the other graphs for the
duration of the Ping/TCP test.
Result Codes: Final status of the test (Success
or Failure)
app, over the Wi-Fi test port
PING
hyperlink at the
to go back to the AutoTest
259
AutoTest App and Profiles
