Wi-Fi Test Port: The internal Wi-Fi test
adapter is a 4x4 Dual-band 802.11ac wireless
radio. To disable, see
testing apps' left-side navigation drawer.

Management Ports

EtherScope can run Discovery, Ping/TCP
Connect tests, Path Analysis, and iPerf tests on
the management ports, but not AutoTests,
packet captures, or Performance tests.
The Management Ports provide a more stable
network connection than the Test Ports, as the
Test Ports may frequently drop link and
reconnect or resume scanning.
Wi-Fi Management Port: The internal Wi-Fi
management port runs on the main Android
system's 1x1 Dual-band 802.11ac + Bluetooth 5.0
wireless adapter, which is configured in the
Android Device Settings. See
Fi to configure this connection.
Wired Management Port: The wired
management port is the RJ-45 port on the
left side of the unit.
