netAlly EtherScope nXG Controlled Edition User Manual page 670

Performance Test App
Changed settings are automatically applied.
When you finish configuring, tap the back
button to return to the Performance test
screen.
Duration: This setting is the length of time the
Performance test runs. Tap the field to select a
new duration. The default is 1 minute.
Services
A Service is a configured traffic flow that
simulates application traffic. You can run up to
four unidirectional or bidirectional services sim-
ultaneously to emulate and test the QoS levels
on your network.
The Services configurations include the
Endpoints, Frame Size, Bandwidth, Thresholds,
and Options the EtherScope uses to measure
and grade performance.
Your collection of configured Services is
available across all of your saved Performance
Test configurations, and if you delete a Service,
it is deleted from all Performance Tests.
On the Performance Settings screen, you can
perform the following actions:
670
