AirMapper™ App
Taking a Connected (Active)
Survey
Use AutoTest to run a Wi-Fi profile and connect
the desired SSID. Touch START to begin the
survey.
If not connected to an SSID, a message is
displayed at the bottom of the screen and the
survey will not start.
Collect data as you would a passive survey
described above.
If the connection is lost, the link notification
changes to an X. EtherScope continuously tries
to reconnect to the SSID.
Survey points taken during this unlinked time
are displayed in Yellow. These indicate areas
where there is not coverage for that SSID.
When you finish adding data points or if you
want to pause the survey, touch STOP.
Touch RESUME to add more data points.
Touch the Link-Live upload icon to send
your survey results to Link-Live's AirMapper
page.
