Http Proxy - netAlly EtherScope nXG Controlled Edition User Manual

AutoTest App and Profiles
See DHCP, DNS, and Gateway Tests for Wired
and Wi-Fi.
Test Targets
Touch the Test Targets field to open the Test
Targets screen and add custom Ping, TCP
Connect, HTTP, or FTP Tests to your AutoTest
profile. See Test Targets to learn more.

HTTP Proxy

The Proxy control lets you specify a proxy
server through which the EtherScope
establishes a network connection. In AutoTest,
these settings are used when HTTP Proxy is
enabled in an HTTP or FTP Test Target.
To use the proxy settings with a web browser,
run the Profile, and then, open the web
browser while the unit remains linked. When
using a web browser, the Wired Test Port takes
priority over the Wi-Fi Test Port, so if you want
to browse via Wi-Fi proxy connection, unplug
the (top) Wired Test Port.
Open the HTTP Proxy screen to enable proxy
settings.
293
