AutoTest App and Profiles
Like the main AutoTest screen, Wired Profile
tests are summarized on cards. Touch a card to
view individual test screens.
Each test icon (except the switch) displays
green, yellow, or red to indicate the status of
the completed test step: Success/Warning/Fail.
The Switch Test card shows the name and port
of the nearest switch, but does not turn green
to indicate success.
When Wired Profiles Run Automatically
The last enabled Wired Profile in the currently
active Profile Group runs automatically when a
copper cable is connected or energy is detected
to the top RJ-45 port, unless the AutoTest app
is open in the foreground and there is more
than one enabled Wired Profile. A Wired Profile
does not start automatically if Periodic
AutoTest is running.
After a Wired Profile runs, a wired network link
is maintained for further testing. Wired Test
Port linkage is indicated in the top Status Bar
with this notification icon: .
