NOTE: If the AutoTest app is not currently
open, the last Wired Profile in the profile list
runs automatically when you power on the
unit or EtherScope detects a new copper link
in the top
See Buttons and Ports
descriptions.
Powering On
To start up the unit, hold down the power
l
button for approximately one second, until
the power button LED turns green.
When the display goes into Sleep mode, the
l
power LED remains on. Touch the power
button briefly to wake up the display. Set
the timing for display sleep and auto power
off in the
To shut down or restart, hold the power
l
button for one second until the "Power off"
and "Restart" dialog box appears on the
touchscreen, and then touch Power off or
Restart.
Wired Test
Device
Port.
for port locations and
Settings.
