netAlly EtherScope nXG Controlled Edition User Manual page 639

The units (feet or meters) displayed in the
AirMapper app are set in the
Settings
left-side navigation drawer
Signal Propagation: This setting is the
radius measurement of the sample points.
Touch the field to adjust the size of the
data points on the map.
Touch back
AirMapper settings.
When you finish configuring, touch
return to the main AirMapper screen.
Floor Plan from Link-Live
Floor plans can now be configured on Link-Live
and send to the EtherScope. A notification
appears when a new floor plan arrives.
The new floor plan is added to the existing
floor plans, but not selected.
for the test apps, accessed from the
to return to the main
639
AirMapper™ App
General
.
to
