User Guide
360mc/400mc
Part No. 107166-0010, Rev. J

Advertisement

Table of Contents
loading

Related Manuals for Stratasys FORTUS 360mc

Summary of Contents for Stratasys FORTUS 360mc

  • Page 1 | c-support@stratasys.com User Guide 360mc/400mc Part No. 107166-0010, Rev. J...
  • Page 2 Liability Statement The information in this document is subject to change without notice. Stratasys, Inc. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 Production Systems which are referred to throughout this User Guide as the 360mc/400mc. These systems incorporate the latest in innovative technologies to provide you with precise prototypes from a CAD design. Stratasys’ Fused Deposition Modeling (FDM) technology provides prototype parts, including internal features, that can be used to field-test form, fit, and function.
  • Page 4 Adds Material Auto-Changeover About This Guide This guide is your introduction to building prototypes using a Stratasys rapid prototype system. It is designed as a learning and reference tool that explains system operation in an easy to understand, step-by-step, process.
  • Page 5 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Conventions Used in This Guide The following conventions are used in this guide. • When you see text in , it indicates a menu item this font that can be selected from the Operator Panel Screen. For...
  • Page 6 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide...

  • Page 7: Table Of Contents

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Table of Contents Table of Contents ................. 1-vii Service and Support ...............1-1 360mc/400mc Service .................. 1-1 Software Support ..................1-1 Safety Instructions..................1-2 Hazard Types..................... 1-2 Product Safety Signs................. 1-3 Specific Safety Practices ................. 1-4 Guard Door Interlocks................
  • Page 8 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Opening the Top Door and Top Hood ........... 3-4 XY Gantry Assembly.................. 3-4 Head Assembly ....................3-5 Head Maintenance Bracket..............3-6 Modeling Materials and Tips ................. 3-7 Materials..................... 3-7 Liquefier Tips....................3-8 Oven Bay ...................... 3-11 Oven Door ....................
  • Page 9 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Handling/Storing Canisters ..............4-20 Changing Tips or Material Type ............4-21 Working with the Job Queues ..............4-29 Change Modeler Default Values ............... 4-30 Display Units..................... 4-30 Part Build Location.................. 4-30 System Status ....................4-32 Temperature Status ................
  • Page 10 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide XY and Z Tip Offset - Manual Start............6-10 System Maintenance ..............7-1 Updating Controller Software................ 7-1 Web Method (preferred method) ............7-1 CD Method (alternate method) ............. 7-2 Placing System in Receive Software Upgrade Mode ......... 7-2 Maintenance Schedule.................
  • Page 11 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Tool Maintenance ..................A-6 Support Removal Tool Kit ................. A-7 Reheating a PPSF Part.................. A-10 Reheating with the Modeler Oven............A-10 Reheating with a Convection or Consumer Oven ......A-10 Reheating with Laboratory Ovens............A-11 Reheating with a Hot Air Gun ...............
  • Page 12 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Removing Parts from the Tank ..............C-11 Changing Solution in the Tank ..............C-12 Disposing of Soluble Concentrate ............. C-13 Soluble Solution Drain Effluent .............. C-13 Neutralization..................C-13 SR-100 Support Removal Quick Reference .........D-1 Minimize Cleaning Time in Support Removal Tank Solution .....

  • Page 13: Service And Support

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 1 Service and Support 360mc/400mc Service If you have a problem with your 360mc/400mc that is not covered in this User Guide, please contact Stratasys Customer Support: • Call (800) 801-6491 (7:00 a.m. to 5:00 p.m. C.T.) •...

  • Page 14: Safety Instructions

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Safety Instructions Hazard Types Stratasys recommends that all services be performed by qualified personnel. All personnel working on or around this system should be knowledgeable of what the following hazard classifications mean throughout this guide.

  • Page 15: Product Safety Signs

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Product Safety Signs We make every effort to ensure that our systems are safe and reliable at all times. However, there will be times when you must access areas of the system where potentially high voltages, hot temperatures, and/or moving mechanical components could cause severe injury.

  • Page 16: Specific Safety Practices

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Specific Safety Practices The following components and areas of the system are highlighted as potential safety hazards that may cause system failure or reliability problems if proper safety procedures are not followed. Warning: Always wear safety gloves and long sleeves when Oven....

  • Page 17: General Safety Practices

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide General Safety Practices Abide by these general safety practices when working with this system. High Voltage: High voltage is present in the system when powered off and unplugged due to the Uninterruptible Power supply (UPS).
  • Page 18 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide...

  • Page 19: Setup And Installation

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 2 Setup and Installation General Information Prepare Your Facility for Installation Follow the 360mc/400mc Site Preparation Guide to ensure that your facility is effectively and safely prepared for system installation. Identifying Your System...

  • Page 20: Making The External Air Connection

    (as viewed from the rear). High voltage is applied to the system via a Delta connection. The main breaker must be off until a Stratasys Service Technician has verified the connection. This system is only provided with a Delta connection.

  • Page 21: Network Setup

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Network Setup Your system is configured for your network as a part of its initial installation and setup. This section is provided in case you have need to change your network settings. Configuring the Network The network address can be Dynamic or Static.
  • Page 22 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select and press ENTER. Network Configuration >Network Configuration.. Receive Software Upgrade or Code..<E> Field Service.. password: Choose for the Dynamic IP Dynamic IP: YES <E> UpnP: ON <E> *Configure Static Network Address Dynamic IP: NO <E>...

  • Page 23: Moving The System

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Moving the System If you need to move the system to a different location, a specific sequence of steps must be followed. Unload material filament from the liquefiers. See“Unloading Material from the Liquefier Tips” on page 4-12.
  • Page 24 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Secure the XY Gantry: (Figure 2-6) Warning: Use an approved safety ladder to access the hood. Open the hood door and hood lid. Manually position the gantry in the left front corner of the XY table.
  • Page 25 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Raise the support feet located near each caster by loosening the locknut on each foot (Figure 2-7). Figure 2-7: System Castors Locknut Caution: If the system will be rolled over floor seams or bumps, do not roll the system on the castors.
  • Page 26 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide...

  • Page 27: System Components

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 3 System Components System Protection Main Circuit Breaker If the system encounters a high current surge, the main circuit breaker trips, protecting the system’s electrical and electronic components. The circuit breaker is located at the right, rear corner of the system (as viewed from the rear).

  • Page 28: Access Doors And Panels

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide If power is lost to the modeler • The UPS allows the modeler to complete its cool-down cycle and then shuts itself off. • If power is restored to the modeler during the shut-down process, the shut-down will continue.

  • Page 29: Top Door And Top Hood

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 3-3: Top Door and Top Hood Top Hood Top Door Top Door and Top Hood Allows access to the XY Gantry, head assembly, and four cooling fans. The cooling fans cool the upper area of the XY Gantry and head area. The two fans on the left draw cool air into the system.

  • Page 30: Left Side Door - Upper

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Left Side Door - Upper Allows access to the left side Z stage components. To remove the panel, loosen the four panel retaining screws (the screws do not have to be removed). Left Side Door - Lower Allows access to the air compressor, material drying system, flow meter, and some electronics bay components.

  • Page 31: Head Assembly

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 3-4: XY Gantry Assembly X Axis Servo Motor Head Assembly Y Axis Servo Motor Y Carriage X Carriage Assembly Assembly Head Assembly The head assembly has been designed for use with a wide range of modeling materials.

  • Page 32: Head Maintenance Bracket

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Head Maintenance Bracket The 360mc/400mc is equipped with a Head Maintenance Bracket which places the head in a convenient location for many head maintenance tasks. To place the head in the bracket: (Figure 3-5 &...

  • Page 33: Modeling Materials And Tips

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Modeling Materials and Tips Materials Materials Used The 400mc system can use high strength polycarbonate material (PC); ABS- M30 or ABS-M30i used with SR-20 or SR-30 water soluble supports; ABS- ESD7 used with SR-30 water soluble support, Translucent ABSi, Ultem* 9085, which is certified for use on commercial aircraft, and Polyphenylsulfone (PPSF), which has the highest heat and chemical resistance.

  • Page 34: Liquefier Tips

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Liquefier Tips Liquefier Tips and Slice Heights Two types of liquefier tips are available. Standard tip tips are used for all modeling materials and for Break-Away Supports (BASS) materials and soluble tips are used for soluble support materials. When modeling with materials that use soluble release support material (SR), use the T12SR20 or T12SR30 tip for the support material.
  • Page 35 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Table 3-2: Available Tips Model Material Model Tip Support Material Support Tip ABSi T10, T12,T16, T20 SR-20 T12SR20 ABS-M30 T10, T12,T16, T20 SR-20 T12SR20 ABS-M30i SR-30 T12SR30 ABS-ESD7 T12, T16 SR-30 T12SR30 PC-ABS...
  • Page 36 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Table 3-4: Tip Life Model Support Model Model Tip Life Support Tip Life Material cu. in. cu. cm. Canisters cu. in. cu. cm. Canisters ABSi 10160 T12SR20 4420 ABSi 12620 T12SR20 9010 ABSi 15080 10.0...

  • Page 37: Oven Bay

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide a.ABS-M30/M30i model materials can use SR-20 or SR -30 support materials. Use the T12SR20 tip for SR-20 material (regardless of model tip size) and use the T12SR30 tip for SR-30 material (regardless of model tip size).

  • Page 38: Oven Components

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide >Unlock Door <E> | Calibrate.. Load/Unload Matl.. | Temp Control.. Change Tips/Matl.. | Move Head/Stage.. If the temperature is high, a warning screen may appear. Press ENTER again to unlock the door. Note: Once any door is unlocked and/or opened, system operation cannot be resumed.
  • Page 39 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide The platen is mounted to the Z stage cross beams with three adjustment screws. This allows the platen to be leveled. The tip sensor is used when performing a Auto tip-to-tip calibration. Figure 3-10: Platen Components...
  • Page 40 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 3-12: Z Stage and Oven Components Lead Screw Guide Rods Tip Sensor Bearings Z Stage Servo Motor Platen & Build Sheet Drive Belt • The platen and build sheet - provide the build surface. Replace the build sheet every time you build a new part.

  • Page 41: Canister Bay

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Canister Bay Accessing the Bays The canister bays are accessed by opening the canister bay door on the front of the system (Figure 3-13). The canister bay door is not a part of the door safety interlock system and, therefore, can be opened during system operation.
  • Page 42 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide For four bay systems, all 4 bays are also operating bays. Note: Auto Changeover capability is included with the 4-bay option - automatically loading a second canister during a build when the first canister runs out of material (see “Canister Auto Change-over”...

  • Page 43: Smartspool System

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide LED Indicators There is one colored LED light above each canister. The LED indicates the canister condition for each bay (Figure 3-13): • Green – Steady. Material filament has been loaded into the liquefiers.
  • Page 44 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide The CMB file contains an estimate of the material amounts (model and support) required for the part build. The estimate is compared to the amount of material in each canister. If there is not enough material available to finish the part, you are given an option to change canisters before initiating the build.

  • Page 45: Vacuum And Air Dryer Systems

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Vacuum and Air Dryer Systems On Board Vacuum System The vacuum pump generates the vacuum used to hold the build sheet to the platen. The amount of vacuum generated by the pump can be read on the vacuum gauge located above the purge waste bucket.
  • Page 46 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 3-20...

  • Page 47: Operating The System

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 4 Operating the System Basic User Interface and Operations The Operator Control Panel consists of a four-line by 40 character display with keypad. The panel is located on the front right face of the system. The Operator Control Panel is easy to use.

  • Page 48: Using The Keypad

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Using the Keypad The Operator Control Panel has the following keypad buttons (Figure 4-2): Figure 4-2: Keypad Buttons Button Description MENU Takes you up one level in the menu directory, unless stated other- wise.

  • Page 49: Screen Symbols

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Screen Symbols The following symbols are used in the menu displays. Symbol Description <E> Push ENTER to execute the command line. (The cursor “>” must be on the same line.) <E>.. Push ENTER to execute command line. Also pushes you into another menu.

  • Page 50: Powering Down The System

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Powering Down the System Warning: due to the UPS, High voltage is present in the system when the power cord is unplugged. Caution: Do not turn the blowers off prior to the five minute time-out or damage to the system may occur.

  • Page 51: Basic Job Build Tasks

    Note: Using build sheets not provided by Stratasys may impact part quality and system reliability. Note: ABS and PC parts use a clear build sheet. PPSF and Ultem* 9085 parts use an amber-colored build sheet.
  • Page 52 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Check the vacuum gauge (located in the canister bay). • Vacuum should read -15 Hg or higher (more negative) before building a part. • The system should attain this level of vacuum within about five minutes.

  • Page 53: Select A Job To Build

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select a Job to Build From the Main Menu select and press ENTER. Build Job >Build Job.. |*Tips: Model T16 Operator Control.. Support T16 Modeler Status.. Maintenance.. Select one of job build options: >Build Next Job:...

  • Page 54: Build Job Warnings

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide is set to , you are offered the User Placement on Platen following choices: Note: For more information about User Placement on Platen “Display Units” on page 4-30. >Locate Part Start.. Demo Bounding Box Continue..

  • Page 55: Information Available During A Build

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Replace Model (or Support) tip with T12.. • Indicates a mis-match between installed tip and tip for which the part (CMB) file was processed. • Install the correct tip. Replace Worn Model (or Support) Tip..

  • Page 56: Pausing Or Aborting A Job

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Pausing or Aborting a Job During a part build, the system can be paused: Automatically (canister runs out of material, failure detected, etc.) Note: If an automatic pause occurs, press the HELP key to view the cause.

  • Page 57: After A Job Build

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide After a Job Build Warning: Wear proper safety equipment when handling items inside the oven. Surfaces in the build chamber can be very hot. The system performs the following actions: The Z stage is lowered and the head is parked.

  • Page 58: Removing Supports

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Removing Supports Breakaway Support Material PC material uses break-away supports, called BASS. This material must be removed manually. Warning: Wear safety goggles and LEATHER gloves (provided in Startup Kit) when removing breakaway supports Remove the support material carefully.

  • Page 59: Removing Canisters

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select and press ENTER. Load/Unload Mtl.. Unlock Door <E> | Calibrate.. >Load/Unload Mtl.. | Temp Control.. Change Tips/Mtl.. | Move Head/Stage.. Select and press ENTER. Unload Material.. Load Material.. >Unload Material.. Material Status..
  • Page 60 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide removing an SR20 support canister, this piece may break off as the canister is removed. Make sure that the broken piece drops out of the drive block. If necessary, remove the drive block inlet to remove this piece of material.

  • Page 61: Canister Installation

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Canister Installation Install the Canister (refer to Figure 4-3 for referenced item numbers): For new canisters, peel back the foil tape (item 1) on the side of the canister. Remove and discard the anti-rotation plug (item 2).
  • Page 62 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 4-3: Canister Installation Key to Figure 4-3 Item Description Item Description Foil Tape Plastic Plug (sealing position) Anti-Rotation Plug Plastic Plug (stowed position) Thumbwheel Door Foam Gasket (sealing position) Canister Snout Foam Gasket (stowed position)
  • Page 63 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 4-4: Preloading Filament Filament Present Switch Drive Lever Filament Drive Wheels Filament Thumbwheel Filament Preload Filament to the Drive Wheels Open the thumbwheel door. Remove the square foam gasket on the inside of the thumbwheel door.

  • Page 64: Loading Material To The Liquefier Tips

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide The system automatically completes the preloading of the filament. • The drive motor advances the filament until it contacts the filament present switch. • The drive motor stops, and the LED turns to green flashing.

  • Page 65: Canister Auto Change-Over

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select the material to be loaded and press ENTER. (The <E> indicates the canisters that you can select.) Note: Model and support materials must be compatible. If a selected material is incompatible with a loaded material, a material mis-match load error will occur.

  • Page 66: Handling/Storing Canisters

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide While the changeover is taking place, the user panel displays: * Auto Changing Material* * On Model Head Please Wait ..• No user interaction is required. • Auto Changeover takes about five minutes.

  • Page 67: Changing Tips Or Material Type

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Close the thumbwheel door - make sure that it is completely closed. Remove the plastic cap from its stowed position (item 6B) and insert it into the filament outlet hole of the canister snout (item 4 &...
  • Page 68 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select and press ENTER. Unload Model and Support.. >Unload Model and Support.. <E> *2. Insert new canisters (if required) *3. Install tips Select Materials/Tips.. • The head warms up to the material operating temperature, and the canister LED rapidly flashes green.
  • Page 69 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 4-6: Tip Installation Make sure Tip is fully inserted into block. Remove the head from the maintenance bracket and place it back in the gantry. Tighten the two captive screws - close the top hood and top door.
  • Page 70 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide • If the bay does not have a canister, the space for the bay information is left blank. The type of support material selected for loading to the liquefier is shown. S* - labels the second half of the line as support information.
  • Page 71 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide - indicates that the material is the current • (*Ready) selection for loading to the liquefier tip. - indicates that a canister is installed, but has • (None.) not been pre-loaded to the canister bay drive wheels.
  • Page 72 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide • If a used tip is installed for which previous odometer information is available, enter the stored reading of the used tip (use the number keys and decimal (.) key), then press ENTER.
  • Page 73 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide viii. The oven and oven temperature must stabilize. Oven stabilization times for the material you are running are listed in Table 4-1. Waiting h:mm to stabilize ** Actual 100 C Setpoint: 225 C >Unlock Door <E>...
  • Page 74 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide The system loads model and support material. Note: If model or support loading fails, manually load or unload the material (“Material, Canisters, and Liquefier Tips” on page 4-12 “Loading Material to the Liquefier Tips” on page 4-18).

  • Page 75: Working With The Job Queues

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Working with the Job Queues There are two, separate, job queues available on the 360mc/400mc - the Job Queue; and the Sample Job Queue. From the Main Menu select and press ENTER. Build Job >Build Job..

  • Page 76: Change Modeler Default Values

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide • Use the arrow keys to scroll up or down through the available sample jobs, or to select a job in the sample queue. • Press the Enter key to build the selected job.
  • Page 77 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide the modeler to define part placement on the platen) can be viewed or changed from the following menu: Note: This menu is displayed when a part is sent to build (refer to “Select a Job to Build” on page 4-7).

  • Page 78: System Status

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide System Status The user interface can be used to display each of the following: • Temperature Status • Odometer Status • Material Status • System Software Version • Other System Information Temperature Status...

  • Page 79: Material Status

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select and press ENTER. The current status of the tips is Tip Status displayed. Temperatures.. Material Status.. >Tip Status.. Machine State Mat’l amount *Model tip 13.0 in3 *Support tip : 54.0 in3 *Tips: Model <T16>...

  • Page 80: System Software Version

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide System Software Version The system can display the version of the software used to control the modeler (this software is installed on the modeler hard drive, not to be confused with Insight software installed on the workstation PC).

  • Page 81: Miscellaneous Operating Tasks

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Miscellaneous Operating Tasks Oven Temperature Control The oven modeling temperature is determined by the loaded material type. It is controlled by the system software and cannot be modified. However, the operator does have control of some oven temperature functions.

  • Page 82: Operator Control Of Head And Z Stage Movement

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Operator Control of Head and Z Stage Movement Moving the Head to the Head Service Location (and Service Bracket) From the Main Menu select and press ENTER. Operator Control Build Job.. |*Tips: Model T16 >Operator Control..
  • Page 83 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Select and press ENTER. Move Z Stage to Bottom Move Head to Service Location <E> Move Head to Center-Front Location<E> >Move Z Stage to Bottom <E> Move Relative.. Incrementally Moving the Z Stage and Head Set the amount of movement the Z Stage and Head will move with each movement command.
  • Page 84 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Warning: When moving the Z stage, be careful not to run it into the head. When the Z stage gets close to the top, toggle the set distance to 0.010 (0.254 mm) or 0.001 inches (0.0254 mm).

  • Page 85: Operating Insight

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 5 Operating Insight Getting Started with Insight Starting Insight To start Insight, select Start>Programs>Stratasys>InsightVxx>Insight. You can also double-click on the Insight shortcut desktop, if it was installed. Opening an STL File To open the file for the part you wish to build: Click File>Open.

  • Page 86: Modeler Setup - Insight

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Modeler Setup - Insight Configure Your Modeler The first step in preprocessing is to configure your modeler. Click the Modeler button located in the Modeler Setup window (right side of screen) of the Operations Panel. The Configure Modeler dialog box opens.

  • Page 87: Part Build Parameters

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Part Build Parameters The second step in preprocessing a model is to choose the part build parameters. The part build style will determine the type of fill pattern used to build the part. The part interior style will determine whether the interior of the part is solid or not.

  • Page 88: Preparing The Model - Insight

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Preparing the Model - Insight Orienting the Part in the Build Envelope The modeling build envelope box displayed in Insight indicates the size of the part relative to the build envelope inside the 360mc/400mc.

  • Page 89: Slicing The Part

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Slicing the Part Before the part file is sent to the 360mc/400mc, the file must be sliced into the layers that the 360mc/400mc will extrude to construct the part. Click the Slice button to create slice curves for the part.

  • Page 90: Saving The Toolpath (Cmb File)

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Saving the Toolpath (CMB file) Now that the part file is sliced and ready to send to the 360mc/400mc, it must be saved as a.CMB file, which can be received by the system.

  • Page 91: Sending A Part To The Modeler

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Sending a Part to the Modeler The process of sending a part to a modeler is dependent upon the associated FDM application that you have purchased (FDM Control Center). Note: FDM Control Center is an application that works with the Insight software to create packs and send part build commands.
  • Page 92 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide...

  • Page 93: Calibration

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 6 Calibration Automatic Calibration After tips are changed the user menu will prompt you to perform a series of automatic calibrations: Auto Z Stage Zero Calibration, Auto Tip-to-Tip Calibration, and XYZ Offset Calibration Note: Perform an Autohome XYZ before initiating automatic calibration (Operator Control >...

  • Page 94: Auto Tip-To-Tip Calibration (Autocal Tip Offset)

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Auto Tip-to-Tip Calibration (AutoCal Tip Offset) Auto Tip-to-Tip Calibration calibrates the tip to tip offsets in the Z direction. No operator interaction required. The system automatically performs this calibration after the tips are changed or after a material type change.
  • Page 95 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 6-1: Calibration Model - English Units Tip Offset Adjustment Indicators X - Y Support Calibration Toolpath X - Y Alignment Example: Best Indicators Centered Position Z Calibration Box This example requires an adjustment to Y of -0.002 in.
  • Page 96 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Determine the Z Adjustment Note: Do not measure for Z adjustment until the Calibration Model shows the XY Offset to be less than 0.002 inch (.05 mm) for the X and Y axis.
  • Page 97 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Enter the XY and Z Tip Offset Adjustment Values From the Main Menu select Operator Control and press Enter. Build Job.. |*Tips: Model T16 >Operator Control.. Support T16 Modeler Status.. Maintenance.. Select Calibrate and press Enter.

  • Page 98: Manual Calibration

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Manual Calibration Manual Z Stage Zero Note: If the Auto Z Stage Zero calibration fails, Manual Z Stage Zero Calibration must be performed. This procedure manually sets the model liquefier tip to the Z Zero location.
  • Page 99 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Using the operator control panel, raise the platen until the build sheet is almost touching the model liquefier tip. • Press 3 on the number pad to raise the platen. • Press 9 on the number pad to lower the platen.

  • Page 100: Auto Z Stage Zero Calibration - Manual Start

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Auto Z Stage Zero Calibration - Manual Start Note: An Auto Z Stage Zero Calibration must be performed after running “Manual Z Stage Zero” on page 6-6. Use this procedure to manually initiate the calibration.

  • Page 101: Auto Tip-Tip Calibration (Autocal Tip Offset) - Manual Start

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Auto Tip-Tip Calibration (AutoCal Tip Offset) - Manual Start Note: An Auto Tip-to-Tip Calibration must be performed if the initial automatic calibration fails. Use this procedure to manually initiate the calibration. “Auto Z Stage Zero Calibration - Manual Start” on page 6-8 must be performed before running the Auto Tip-to-Tip Calibration.

  • Page 102: Xy And Z Tip Offset - Manual Start

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide XY and Z Tip Offset - Manual Start Note: If the support layer is not centered on the model layer, an XY and Z Offset should be performed. Note: Perform an “Auto Tip-Tip Calibration (AutoCal Tip Offset) - Manual Start”...

  • Page 103: System Maintenance

    Open the Control Center application and select the Services tab and then click Check for System Updates. The Stratasys Update Manager window will appear. The application will check to see if the Controller software is current. Follow screen prompts to update the Controller software.

  • Page 104: Cd Method (Alternate Method)

    Fortus 360mc/400mc. When the download is complete, select Reboot and Install Software Upgrade and then press OK at the Fortus 360mc/400mc system. After the system reboots and the upgrade installation complete, two options will appear; select Auto Home XYZ.

  • Page 105: Maintenance Schedule

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Maintenance Schedule Maintenance tasks must be performed on a regular basis in order to maintain optimal system operation. Table 7-1 outlines the general maintenance schedule. Detailed instructions for each task make up the rest of this chapter.

  • Page 106: Daily Maintenance

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Daily Maintenance Clean the Platen The platen is the surface on which the build sheet is placed for modeling. If debris collects on the platen, it can adversely affect the vacuum which secures the build sheet to the platen.

  • Page 107: Weekly Maintenance

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Weekly Maintenance Vacuum the Build Envelope Vacuum the build envelope to remove build material waste and dust. Clean/Inspect Tip Wipe Assembly You should inspect the tip wipe assembly once a week. Replace parts as necessary when wear is detected.
  • Page 108 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide • The Kapton tape is secured to the upper funnel chute with self- adhesive material. To replace the tape, peel the tape from the chute. • Clean the area around the top of the upper funnel chute with Isopropyl alcohol and a clean, lint-free cloth.
  • Page 109 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure 7-5: Tip Wipe Assembly Flicker/Brush Purge Surface Assembly Style may vary depending on material type Brush Flicker Loosen and remove screw to replace flicker.

  • Page 110: Quarterly Maintenance

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Quarterly Maintenance Inspect the Platen O-Ring Check the platen o-ring for cracks, cuts, nicks, etc. - none allowed. Replace the o-ring as necessary. Remove the o-ring from the groove around the platen. • No special tools or techniques are required. The o-ring is held in place by contact pressure.

  • Page 111: Clean The Tip Sensor Plunger

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Clean the Tip Sensor Plunger Remove the plunger - gently pull up and out (Figure 7-7). Remove material residue on the top of the plunger with a razor blade. Replace the plunger in the sensor bracket - make sure the flat surface is...

  • Page 112: As Needed Maintenance

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide As Needed Maintenance Upgrading Software or Entering a System Code Upgrades to controller software and system codes are uploaded to the system. Note: To upgrade system controller software, or to enter a system change code, access to an Insight workstation is required.

  • Page 113: Platen Flatness Diagnostic

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Open the Insight FDM CC application. From the Name: drop-down list, select your the 360mc/400mc machine. Access the Services Tab. • From FDM CC: click the Services Tab. Use the appropriate button (‘Update Software’, ‘Setup Code’) to upload the change to the modeler.

  • Page 114: Clean Exterior Surface Of System

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Clean Exterior Surface of System Exterior surfaces of the system may be cleaned using a lightly damp cotton cloth. Clean the oven door glass with a cleaner that does not contain ammonia. Clean the Liquefier Tips The system automatically cleans the tips before and during each part build - using the tip cleaning assembly.

  • Page 115: Troubleshooting

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Chapter 8 Troubleshooting Getting Help If you have problems with your system or materials, that are not covered in this user guide or in the T-Class Quick Reference Card, or if you need to order...

  • Page 116: Finding A Remedy

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Finding a Remedy Condition Possible Cause Remedy Canister will not load Anti-rotation plug not Remove plug. removed from canister. Rubber thumbwheel insert Remove thumbwheel insert. not removed from thumb- wheel door. Empty canister (zero volume) Replace canister.
  • Page 117 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Condition Possible Cause Remedy Loss of extrusion Filament stuck in canister Remove canister from system and pull (Head will not extrude out about 8 feet (2 meters) of material material) out. Ensure filament pulls out freely.
  • Page 118 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Condition Possible Cause Remedy Low Vacuum The build sheet is not properly Move the sheet until it overlaps the (Vacuum gauge does installed. platen equally on all sides. not read -15 or There is filament debris on the...
  • Page 119 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Condition Possible Cause Remedy Oven not maintaining Heater failure Call Customer Support. temperatures Oven door open. Close the oven door; the heater turns off while the door is open. Oven door not sealing with Call Customer Support.
  • Page 120 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide...

  • Page 121: Ppsf Materials User Guide

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Appendix A PPSF Materials User Guide Introduction to PPSF Polyphenylsulfone (PPSF) is an engineering grade thermoplastic with superior mechanical, thermal, and chemical properties. With an HDT of 189° C (372° F), you can perform a wider range of tests at higher temperatures, giving you more accurate information.

  • Page 122: Hazard Classifications

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Hazard Classifications Stratasys recommends that only qualified personnel handle PPSF and PPSF_S. The following hazard classifications are used in this guide and should be understood by those who handle the material. Caution: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

  • Page 123: Modeler Operation With Ppsf

    Switching to PPSF From Another Material Replacing the Tip Stratasys recommends installing new tips and shields each time you change to PPSF from another material (for best results). See “Changing Tips or Material Type” on page 4-21. Note: When building with PPSF and PPSF_S, a T16 tip will have an operating life of approximately two canisters.

  • Page 124: General Operation With Ppsf

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide General Operation with PPSF Only use the amber plastic build sheet when building with PPSF. Damage to the modeler will occur if other build sheets are used. Only use a PPSF build sheet ONCE.
  • Page 125 You can remove supports from one part while the others are heating up. The difficulty of support removal is based on the following: part size, amount of supports, support style, and support temperature. Stratasys recommends removing the supports in the following order: Base...

  • Page 126: Using The Support Removal Toolkit Items

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Using the Support Removal Toolkit Items The Support Removal Toolkit contains several tools that are specifically designed to remove FDM supports. The figures and table in this section will help you learn about how and when to use the tools.

  • Page 127: Support Removal Tool Kit

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Support Removal Tool Kit Item Description and Usage Safety Gloves The safety gloves are leather and heat resistant, shielding hands from minor cuts while removing supports. Safety glasses with Safety glasses must be worn for your safety while removing supports in hanging cord case of flying particles from the supports.
  • Page 128 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Item Description and Usage Straight Chisel The straight chisel removes the support faces from the part and is the most versatile tool. Tips Hold the straight chisel bevel down in the palm of your hand.
  • Page 129 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Item Description and Usage Gouge The gouge removes supports in holes and concave parts. The gouge reduces the chances of cutting into the part and gives you a closer cut. Tips Push the gouge bevel up into a hole or concave part.

  • Page 130: Reheating A Ppsf Part

    Reheating with the Modeler Oven Stratasys recommends using the modeler oven to reheat a part because of its temperature control and effective airflow. Place the part on the vacuum platen when reheating. Do not put the part underneath the Z stage; the bottom of the oven may get too hot for the part to withstand.

  • Page 131: Reheating With Laboratory Ovens

    Reheating with a Hot Air Gun If you choose to use a hot air gun, Stratasys recommends using an electronically controlled hot air gun with an adjustable temperature and air flow.

  • Page 132: Sealing/Adhesive Data

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Sealing/Adhesive Data Weldon 3 American Seal All Devcon 5 Satellite Standard, Minute City #HS-4 Epoxy P/S Fuel Hot Stuff Tank Instant Sealant, Glue PQR 15 Brush or dip Brush or dip Brush Brush...

  • Page 133: Ui Menu Structure

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Appendix B UI Menu Structure Main Menu 1 - Main Menu Build Job.. |*Tips: Model T16 >Operator Control.. Support T16 Modeler Status.. Maintenance.. 2 - Build Job.. >Build Next Job: “Name of Job” <E>...
  • Page 134 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 1 - Main Menu Build Job.. |*Tips: Model T16 >Operator Control.. Support T16 Modeler Status.. Maintenance.. 2 - Operator Control Unlock Door <E> | Calibrate.. >Load/Unload Mtl.. | Temp Control.. Change Tips/Mtl.. | Move Head/Stage..
  • Page 135 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 4 - Material Status.. ** Model 1:PC 92.3 in3 (Ready) * Model 2:PC 67.1 in3 (Loaded) ** Support 1:PC_S 92.3 in3 (Loaded) * Support 2:PC_S 0.0 in3 (Empty)1 4 - Unplug Tips.. ***** Head Purge Buttons Activated *****...
  • Page 136 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 5 - Reset Tip Odometers.. (if user placement on) >Reset Model in3 <E> 633.5 () Reset Supp. in3 <E> 182.7 () Select Calibration Part Position.. Unlock Door <E> 5 - Reset Tip Odometers.. (if user placement off) Reset Model in3 <E>...
  • Page 137 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 6 - The following screens display automatically: * Waiting h:mm to stabilize ** Actual 100°C Setpoint: 225°C >Unlock Door <E> | Vacuum On Calibrate Immediately <E> Tip to Tip Calibration Activity Please Wait...
  • Page 138 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 5 - Set Manual Z Stage Zero.. *Positioning. Please Wait... Unlock Door <E> Set Distance= 0.100 in <E> >Set Z Stage= 0 <E> (Z: 0.010) *Move Z Stage: +Z<9> -Z<3> 5 - Modify Current Z Zero..
  • Page 139 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 3 - Move Head/Stage.. Move Head to Service Location <E> Move Head to Center-Front Location<E> Move Z Stage to Bottom <E> >Move Relative.. 4 - Move Relative.. >Set Distance= 0.100 in <E> *Move Head: +X <6> -X<4> +Y <2> -Y <8>...
  • Page 140 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 3 - Material Status.. ** Model 1: PC 56.4 in3 (Loaded) * Model 2: in3 (None) ** Support 1: PC_S 21.4 in3 (Loaded) * Support 2: in3 (None) 3 - Tip Status.. * Mat’l amount *Model tip : 0.0 in3...
  • Page 141 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 4 - System Status.. Last Built Layer = XX Serial Number = XXX UPS Type = Invensys or Best Power SERVO ID = XX HEADBOARD FIRMWARE = X.X MIO BOARD FIRMWARE = X.X AC BOARD FIRMWARE = X.X...
  • Page 142 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 1 - Main Menu Build Job.. |*Tips: Model T16 Operator Control.. Support T16 Modeler Status.. >Maintenance.. 2 - Maintenance.. >Modeler Default.. Administration.. Reboot Machine.. Procedures.. 3 - Modeler Default.. >Display Units = in (Inches) <E>...
  • Page 143 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 5 - Configure Static Network Address (Dynamic IP = NO ) >IP : [172.16.70.10] MASK: (.none found) [172.16.100.1] 4 - Receive Software Upgrade or Code.. >Waiting for Software Upgrade or Code Press MENU key to Cancel 3 - Reboot Machine..
  • Page 144 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide 4 - Menu after head power is turned Off *OK to Install New Head Reboot System <E> B-12...

  • Page 145: Waterworks

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Appendix C WaterWorks About WaterWorks Soluble Concentrate ™ WaterWorks in combination with Stratasys’ soluble support materials dissolves temporary support structures with a water based solution, rather than manually removing support material or using solvents to clean parts.

  • Page 146: System, Material, And Liquefier Tip Compatibility

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide System, Material, and Liquefier Tip Compatibility ABS (P400) Use ABS model material with ABS_SS support material. The following tip combinations and slice heights are available: FDM Vantage and FDM Titan FDM Maxum Model Tip...

  • Page 147: Absi (P500

    ** T10 Slice is not available for Fortus 900mc. ABSi (P500) ABSi material is only available on Titan, Vantage Xa, Vantage S, Vantage SE, FDM Maxum, Fortus eV, Fortus eT, Fortus 360mc/400mc and Fortus 900mc systems. Use ABSi model material with ABS_SS support material. The following tip...

  • Page 148: Pc-Abs

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide PC material is available for Fortus eV, Fortus eT, Fortus 360mc/400mc, and Fortus 900mc systems. Use PC model material with SR-100 support material. The following tip combinations and slice heights are available: Fortus eV, eT, 360mc/400mc, and 900mc...

  • Page 149: Tip Identification

    Fortus System Tip Identification When building with WaterWorks material using a Fortus eV, Fortus eT, Fortus 360mc/400mc or Fortus 900mc system, the T12 SR support tip must be used for all indicated model tips. The T12SR20, T12SR30, and T12SR-100 tips are clearly marked on the top-side of the plate and are slightly shorter than the model tips.

  • Page 150: Choosing A Support Removal Tank

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Choosing a Support Removal Tank Agitation aids WaterWorks in support material removal. Stratasys recommends using either a circulation or an ultrasonic tank. The tank must be able to withstand a solution temperature up to 85 °C (185 °F), and high alkaline solutions with a pH level up to 13.

  • Page 151: Safety Guidelines

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Safety Guidelines Observe the following safety guidelines when using the soluble concentrate and the tank: • Follow the manufacturers documentation on tank operation and safety. Understand how to properly and safely use the tank before operation.

  • Page 152: Removing Support Material

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Removing Support Material Manually Removing Support Material Warning: Always wear safety glasses and safety gloves when removing support material by hand. The support material is very brittle and can become shards when manually broken off.

  • Page 153: Tank Temperature

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Tank Temperature Caution: Never turn on power to the tank heater or ultrasonic units without water or solution in the tank. Power on the tank according to the operating instructions set by the manufacturer.

  • Page 154: Inspecting Parts And Solution

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Inspecting Parts and Solution Support material can be washed away from part geometries in 0.5 to 3.0 hours in the support removal tank solution using proper temperature (see “Tank Temperature” on page C-9) and pH levels. Parts exposed to the WaterWorks solution for less than 24 hours should see no change in mechanical properties.

  • Page 155: Removing Parts From The Tank

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Removing Parts from the Tank Warning: Always wear safety goggles and heat, alkaline, and water-resistant gloves when removing parts from the tank. Turn off power to the tank. Carefully remove parts from the tank or optional stainless steel container.

  • Page 156: Changing Solution In The Tank

    Changing Solution in the Tank How often the solution is changed is dependant on the tank used, how it is maintain, and the complexities of the parts built. Stratasys recommends changing the solution after removing approximately 25 cubic inches (410 cc) of support material.

  • Page 157: Disposing Of Soluble Concentrate

    9-12 Check with local, state, and/or international regulatory statutes for what pH level is acceptable for sewer drain disposal. Stratasys recommends that disposal procedures be verified by the proper authorities. Stratasys cannot anticipate local, state, or international regulatory statutes. Stratasys cannot be held liable if the solution is not disposed of properly.
  • Page 158 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide C-14...

  • Page 159: Support Removal Quick Reference

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Appendix D SR-100 Support Removal Quick Reference Minimize Cleaning Time in Support Removal Tank Solution SR-100 supports can be washed away from part geometries in 0.5 to 3.0 hours in a support removal tank solution with a proper temperature and pH levels (see below).

  • Page 160: Maintain Clean Support Removal Tank Solution

    FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Maintain Clean Support Removal Tank Solution Support removal times can be minimized and part integrity can be maximized by maintaining a “clean” WaterWorks solution in the support removal tank. There are two common methods to determine when the support removal tank solution is no longer “clean”:...
  • Page 161 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide Figure D-1: Pin Side (side view shown), is an example of a geometry susceptible to thermal stresses. Figure D-2: Slight removal of the supports (shown as gray) is between the top and bottom flange will eliminate the thermal stresses imposed on the pin by the SR-100.
  • Page 162 FORTUS 360mc/400mc and FDM 360mc/400mc User Guide...

This manual is also suitable for:

Fortus 400mc

Table of Contents
