Type of threshold for the alert (Rx, Tx, or either).
•
Active or inactive state of the alert.
•
Threshold criteria:
— Percent traffic capacity utilized. This is the percent of the port's throughput
capacity achieved by the measured throughput. This setting constitutes the
threshold value. For example the value of 50 means that the port's threshold is
reached when throughput is 50% of capacity.
— Time interval during which throughput is measured and alert notification can
occur.
— The maximum cumulative time that the throughput percentage can be
exceeded during the set time interval before an alert is generated.
•
Ports for which you are configuring threshold alerts.
You can configure up to 16 alerts, and any number of alerts can be active at one time.
Procedures
Use the following procedures to create a new threshold alert, or to modify, activate,
deactivate, or delete an alert.
Create New Alert
1. Select Threshold Alerts from the Configure menu on the menu bar.
The Configure Threshold Alerts dialog box displays.
edge switch 2/16 product manager user guide
Configuring the Switch
3–29
