Configuring the Switch
— The feature key is a string of alphanumeric characters with dashes. The key is
case-sensitive, so enter the key exactly as printed in the documentation that
you received for the feature. If an error stating "Invalid feature key" displays,
verify that you have entered the feature key correctly.
The Enable Feature Key dialog box displays with a warning, stating that this
action will override the current set of features on the switch. The list in the left
column of the dialog box is a list of features that are active on the switch. The list
on the right is a set of features that come with the new feature key. All of the
features that are active are included in the new feature list.
5. Click Activate to activate the new feature key.
An IPL will occur, during which the Ethernet connection between the HAFM
server and switch is momentarily interrupted.
NOTE: If you click Activate, all current features will be replaced with new features. That is, if
there are features shown in the current list that are not shown in the new list, then those
features will be removed from the switch.
6. Set the switch back online.
7. When you are finished configuring the switch, you can back up the configuration
data. For more information, refer to
Data on page

Configure Date and Time

Use the procedures in this section to display and change the date and time set on the
switch. You must set the current date and time on the switch using this dialog box so
the correct time stamps display in the Event Log, Audit Log, Hardware Log, Link
Incident Log, and Threshold Alerts Log.
NOTE: S/390 mode only. If both periodic synchronization and switch clock alert mode are
enabled, an error will result. Disable one of them to fix the error. Refer to the following
procedure to disable periodic synchronization. Refer to
disable switch clock alert mode.


Set the switch date and time using the following steps:
1. Select Date/Time from the Configure menu on the menu bar.
The Configure Date and Time dialog box displays.
Backing Up and Restoring Configuration
Configure Feature Key on page 3-24
edge switch 2/16 product manager user guide
