ST.TM.E9200.8
Issue 8
ENGLISH (UK)
INSTRUCTION MANUAL
Alteia and Alteia plus
Professional Receivers and Decoders
Software Version 2.1 (and later)
[Demultiplexer App Code Version]
M2/PDU/942, M2/P8R/942, M2/PSR/932,
M2/PSR/942, M2/PTR/94x, M2/PTRE/94x
and Options
Typical Alteia plus Satellite Receiver
