board out of the enclosure and breaks its midplane connection before the board can shut down
properly.
4. Wait for the blue hot swap LED to light. This can take several seconds depending on the
amount of data that must be synchronized.
5. Open the ejector handle fully, rotating it outward until the board disengages from the midplane
(refer to
6. Slide the board evenly out of the enclosure.
7. Install a replacement CMM (see
empty slot with a filler panel to maintain the system's shielding and cooling performance. If
both CMMs are removed without replacement, ensure that BD_SEL# jumpers are installed for
all slots.
3.2

Working with Board-Level Components

The ZT 5085 has slots for up to 18 PICMG* 2.16 node boards and two PICMG 2.16 fabric boards
(see Figure 9, "ZT 5085 Example System (front)" on page
with slot 1 being at the left side of the enclosure and slot 21 at the right.
As discussed in
options for the ZT 5085 chassis:
•
18 independent servers communicating across the PICMG 2.16 Ethernet midplane
•
Redundant host processors controlling with bridged CompactPCI* segments
•
system master processor boards controlling the midplane's two CompactPCI* bus segments
•
One extended CompactPCI bus
Table 4.

ZT 5085 Slot Definitions

1A and 1B
2 and 21
3 – 20
• 9-12
• 3-8 and 13-18
19 and 20
Boards installed at the front of the ZT 5085 may be paired with Rear Panel I/O (RPIO) boards
accessible from the rear of the system (see
page 23).
Caution: Some third-party CompactPCI* boards use latches with alignment pins that insert into tapped
screw holes in the chassis. Intel highly recommends removing the alignment pins prior to insertion
of these boards into the chassis. Insertion of alignment pins into tapped screw holes can generate
metal particles, resulting in product failure. Failures resulting from use of this latch type are not
covered under the Intel warranty.
Technical Product Specification
Figure 16, "Injector/Ejector Operation (Board-Level Components)" on page
Section 1.4, "Configuration Options" on page
Slots
CMM Slots; support redundant Chassis Management Modules.
Fabric Slots; support redundant PICMG* 2.16-compliant Ethernet switch boards.
Support PICMG 2.16 compliant node boards.
Multi-Purpose Slots; support Redundant Host processor boards, system master/
mezzanine combinations, and PICMG 2.16-compliant node connections.
Peripheral/Node Slots; support Peripheral slot capable processor boards and other
32- or 64-bit peripheral boards. Also supports PICMG 2.16-compliant node
connections and PICMG 2.5-compliant H.110 telephony bus connections.
PCI-Less/Node Slots; supports PICMG 2.16-compliant node connections.
Section 3.1.1, "Installing the CMM" on page
22). Slots are numbered 1 through 21,
Application
Figure 10, "ZT 5085 Example System (Rear)" on
Field Replaceable Units
34) or cover the
12, there are four configuration
33).
