Figure 7. Redundant Hosts Controlling Two CompactPCI* Bus Segments
1A
1B
1.4.4
Independent Servers
TheZT 5085 can be used in a configuration that supports 18 independent servers communicating
over the PICMG* 2.16 Ethernet midplane (slots 3-20).
