Intel NetStructure ZT 5515 Product Specification

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
TM
Intel
NetStructure
ZT 5515
Compute Processor Board
Technical Product Specification
June 2004
Order Number: 273813-005
Downloaded from
Elcodis.com
electronic components distributor

Advertisement

Table of Contents
loading

Related Manuals for Intel NetStructure ZT 5515

Summary of Contents for Intel NetStructure ZT 5515

  • Page 1 ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification June 2004 Order Number: 273813-005 Downloaded from Elcodis.com electronic components distributor...
  • Page 2 Except as permitted by such license, no part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the express written consent of Intel Corporation.

  • Page 3: Table Of Contents

    Connectors ......................... 27 Switch Options ........................28 BIOS Configuration Overview ..................... 28 Operating System Installation ..................... 30 Configuration ..........................31 Switch Options and Locations ....................31 ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...
  • Page 4 Strobing the Watchdog ................45 8.2.2 Watchdog NMI ....................... 46 8.2.2.1 Chaining the ISRs .................. 46 8.2.2.2 Enabling the Watchdog NMI ..............47 ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...
  • Page 5 Switch Cross-Reference Table ....................31 SW2-1 Status..........................33 SW2-2 Status..........................33 SW2-3 Status..........................33 SW2-4 Status..........................33 SW3-1 Status..........................34 SW3-2 Status..........................34 ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...
  • Page 6 November 2002 Changed MTBF Changed default switch configuration to show SW 4 Open by November 2002 default. November 2002 Initial release of this document ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 7: Document Organization

    Pentium 4 Processor - M. This board is a single board ® computer designed to work as a modular component in a CompactPCI* system. The Mobile Intel ® Pentium 4 Processor-M is utilized in a micro FCPGA package along with dual Gigabit Ethernet controllers and the latest in memory and I/O technology to provide an inexpensive, yet fast and reliable PICMG 2.16 board.
  • Page 8 Appendix G, “Agency Approvals” presents UL, CE, and FCC agency approval and certification information for the ZT 5515. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 9: Introduction

    Intel. Expansion boards are available to add CompactFlash* (Intel NetStructure ® ™ ZT 96080) in place of the hard drive and rear transition boards (Intel NetStructure ZT 4807) are available to extend I/O access to the rear of a system. For more information about options and ®...

  • Page 10: Zt 5515 Faceplate

    Figure 1. ZT 5515 Faceplate Ejector Handle Video Ethernet CPU Reset Switch COM RS-232 Serial Port Reset LED IDE Activity LED Status LED Hotswap LED Ejector Handle ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 11: Features

    CompactPCI Specification, PICMG 2.16, Version 1.0 compliant (see Appendix D, “CompactPCI”) • 6U single-slot CompactPCI form factor • Mobile Intel Pentium 4 Processor - M, micro FCPGA package ® • Intel 82845E MHC and ICH4 • Dual 10/100/1000 Mb/s Ethernet* (one available at the faceplate or both at the J3 backplane connector) •...

  • Page 12: Functional Blocks

    PICMG* 2.0 compliant chassis without interfering with the CompactPCI bus. The ZT 5515 only uses the J1 and J2 connectors for power and IPMI signaling. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 13: Processor

    2.3.3 Chipset The Intel 845E chipset consists of two controller hubs: the 82845E Memory Controller Hub (MCH) supports a 400MHz or 533MHz system bus, DDR200/266 memory and the latest graphics devices through the 1.5 V AGP4X interface. The 82801DB I/O Controller Hub (ICH4) makes a direct connection to the graphics and memory for faster access to peripherals.

  • Page 14: Pci-To-Pci Bridge (Not Supported)

    +5.0 V 10.0 A 15.0 A +3.3 V 9.4 A 14.1 A +12 V 1.0 A 1.5 A -12 V 0.6 A 0.9 A ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 15: Rear-Panel I/O

    IDE connector on-board nor a hard drive. In contrast, the ZT 5515B-1A does have an IDE connector and hard drive, but does not have a PMC site. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 16: Dual Ethernet Interfaces

    The ZT 5515 provides two 10/100/1000BaseTx Ethernet channels (ENET A and ENET B) through the Intel 82546EB Fast Gigabit Ethernet Multifunction PCI Controller. The 82546EB consists of both the Media Access Controller (MAC) and the physical layer (PHY) interface combined into a single component solution.

  • Page 17: Counter/Timers

    Two cascaded 8237-style DMA controllers are provided on the ZT 5515 for use by the on-board peripherals. The ZT 5515's DMA controllers reside in the Intel ICH4 device. Section D.3, “Intel 845E Chipset” on page 83 for a link to the datasheet for this device.

  • Page 18: Reset

    2.3.20 Baseboard Management Controller The ZT 5515 includes an Intel Baseboard Management Controller (BMC) chip, the VT22030A which interfaces to the LPC bus. The BMC provides SMBus (System Management Bus) interfaces and is IPMI (Intelligent Platform Management Interface) compliant. The BMC subsystem monitors, controls, and performs remote diagnostics for on- and off-board functions.

  • Page 19: Floppy Disk Controller

    Chapter 7, “IDE Controller,” for more information on the ZT 5515’s IDE controller. The ZT 5515’s IDE controller resides in the Intel ICH4 device. Section D.3, “Intel 845E Chipset” on page 83 for a link to the datasheet for this device.

  • Page 20: Software

    The ZT 5515 is compatible with all major PC operating systems, including Microsoft* Windows* 2000, Linux*, and VxWorks*. Intel may provide additional drivers for Intel peripherals, flash drives, and for supported operating systems. Software device drivers for the ZT 5515 can be found on the Intel Website.

  • Page 21: Getting Started

    (P01-Pxx). The revision level is shown in the BIOS Identification string displayed during the Power On Self Test (POST). The revision level is the fourth field in the BIOS ID string. The Intel NetStructure Embedded BIOS Manual is available from Intel's Web site (http:// developer.intel.com/design/network/products/cbp/linecard.htm).

  • Page 22: Connectivity

    The ZT 5515 will not correctly terminate the PCI bus if used in a system master slot since it has no CompactPCI* bus. If you are planning on using the CompactPCI* bus then you should use a board ® that is a CompactPCI* master in the system master slot such as the Intel NetStructure ZT 5504 System Master Processor Board.

  • Page 23: Memory Configuration

    For example, a VxWorks operating system could be loaded into the upper 15 Mbyte and could be used as a boot device. Figure 3 shows example memory addressing for the ZT 5515. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 24: Memory Address Map Example

    Primary IDE Registers decoding is used for the 178 - 1DFh Reserved onboard ISA devices. 170 - 177h Secondary IDE Registers 100 - 16Fh Reserved ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 25: I/O Configuration

    Connectors The ZT 5515 includes several connectors to interface to application-specific devices. Refer to Section A.3.2, “Connectors” on page 62 for complete connector descriptions and pinouts. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 26: Switch Options

    BIOS Configuration Overview This topic presents an introduction to the ZT 5515’s BIOS. For more detailed information about the BIOS and other utilities, see the Intel NetStructure Embedded BIOS Manual available on the Intel Website. The BIOS has many separately configurable features. These features are selected by running the built-in Setup utility.

  • Page 27: Setup Screen

    System Memory: 640 KB Extended Memory: 64512 KB Help Select Item Change Values Setup Defaults Exit Select Menu Enter Select Submenu Save and Exit ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 28: Operating System Installation

    5. Proceed with the OS installation as directed, being sure to select appropriate device types if prompted. Refer to the appropriate hardware manuals for specific device types and compatibility modes of Intel products. OS installation guides for validated operating systems are provided on the ZT 5515 support website under “Installation Guides.”...

  • Page 29: Configuration

    VGA routing (front / back) SW4-1 User Software Configuration 0 SW4-2 User Software Configuration 1 SW4-3 Console Redirection SW4-4 BMC dual domain mode Ejector ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 30: Switch Descriptions

    SW1 is a push-button on the front of the ZT 5515. Pressing SW1 issues a hard reset. Reset is discussed in more detail in Chapter 5, “Reset”. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 31: Sw2-1 (Flash Write-Protect)

    Closing this switch will clear the system CMOS. This switch is connected to GPIO35 of ICH4. Table 7. SW2-4 Status SW2-4 CMOS Real Time Clock Open (Default) Normal Operation Closed Clear CMOS ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 32: Sw3-1 (Bios Recovery Module/Flash Select)

    SW3-4 Function Open (Default) VGA routed to the video connector on the faceplate. Closed VGA routed to the J5 Rear Panel I/O connector. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 33: Sw4-1, Sw4-2 (Software Configuration)

    Open (Default) Console redirection disabled. Closed Console redirection enabled. ® ™ Refer to the “Console Redirection” chapter in the Intel NetStructure Embedded BIOS Manual before attempting to use this feature. 4.2.12 SW4-4 (BMC Dual Domain Mode) The BMC on ZT 5515 is able to work as a Baseboard Management Controller or Satellite Management Controller by toggling the SW4-4.

  • Page 34: Jumper Descriptions

    Normal operation. The BIOS uses its current configuration and password for booting. Configuration mode. After POST runs the system automatically enters the BIOS setup screen and the maintenance menu is displayed. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 35: Reset

    Simultaneously pressing these keys calls a BIOS function that reboots the system. Note: This method does not work under operating systems that trap calls to this BIOS function. Watchdog Timer (System Register Address 79h) ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 36: Backend Power Down Sources

    The watchdog timer may be programmed to generate a non-maskable interrupt if it is not strobed within a given time-out period. This function is discussed in Chapter 8, “Watchdog Timer.” ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 37: System Monitoring And Control

    System Monitoring and Control System Monitoring and Control The ZT 5515 performs system control and monitoring functions using an Intel Baseboard Management Controller (BMC) ASIC, the VT22030A. The BMC has the following features: • IPMB_PWR delivers 5VDC (1A/pin) to the BMC; other required voltages are derived from this power source.

  • Page 38: Field Replaceable Unit (Fru) Information

    Field Replaceable Unit SEEPROM 1010011 System Event Log SEEPROM 1010 011 DDR SDRAM Signal Presence Detect (SPD) PROM 1010000 CK408 Clock generator 1101001 ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 39: Ide Controller

    The ZT 5515A-1B has an on-board IDE controller that provides two IDE channels for interfacing with up to four IDE devices. The IDE controller is incorporated into the Intel 845E chipset which supports ATA-100. There is one 44-pin IDE connector on the ZT 5515A-1B, which supports up to two IDE devices (though there is only space on the board itself to mount one device).

  • Page 40: Ide I/O Mapping

    170h-177h, 376h and interrupt IRQ15. No memory addresses are used. IDE CompactFlash Carrier Intel provides an optional IDE CompactFlash* Carrier (ZT 96080) that can be mounted in the hard drive location on the ZT 5515A-1B (the ZT 5515A-1A does not support this CompactFlash* carrier on the main board because it does not have an IDE connector).

  • Page 41: Watchdog Timer

    The watchdog timer register is cleared on power-up, enabling the system software to take appropriate action if the watchdog generated the reboot. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 42: Power Up Initialization

    WdValue |= WD_RESET_EN_BIT_SET; // Assert the enable bit in // the local copy. outb(WD_CSR_IO_ADDRESS,WdValue); // Assert the enable in the // watchdog register. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 43: Setting The Terminal Count

    C code to strobe the watchdog might look like the following: id StrobeWatchdog(void){ it takes. inb(WD_CSR_IO_ADDRESS); // A single read is all ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 44: Watchdog Nmi

    // the chip set before installing the new vector. // Install the new ISR. oldNmiIsr = getvect(IsrVector); // Save the old vector. setvect(NMI_INTERRUPT_VECTOR_NUMBER, WatchdogIsr);// Install the new. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 45: Enabling The Watchdog Nmi

    WdValue |= WD_NMI_EN_BIT_SET; // Assert the enable bit in the // local copy. outb(WD_CSR_IO_ADDRESS,WdValue); // Assert the enable in the watchdog // register. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 46: Nmi Handler

    // Did the watchdog cause the NMI? if(inb(WD_CSR_IO_ADDRESS) & WD_NMI_DETECT_BIT_SET){ TripAlarm(); // Take care of essential tasks. TurnOffTheGas(); _chain_intr(OldNmiIsr); // Invoke the originally installed ISR. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 47: System Bios

    31). To reprogram the BIOS on the ZT 5515, you should do the following: 1. Download the latest BIOS for the ZT 5515 from the Intel website. Normally, the BIOS zip file also contains the Flash.exe utility you need. 2. Create a DOS 6.2 boot disk and add the BIOS file and flash utility to the disk. Usually other Windows* boot disks will work fine as well, but use DOS if you run into any problems.

  • Page 48: Bios Configuration Overview

    BIOS.XXX is the BIOS image for the ZT 5515. See the Intel NetStructure Embedded BIOS Manual for more information on the flash utility. The BIOS zip file should also contain a Readme file or installation file to help guide you through BIOS installation.
  • Page 49 UINT8 NetworkIDPad; UINT8 BootBlockPage; /* <-- Ver 1.01 starts here */ UINT32 BootBlockAddr; UINT32 FDriveAddr; UINT16 BootBlockSize; UINT16 TotalBiosSize; UINT8 FDrivePage; } ZiaSysInfo; ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 50: Detailed Structure Element Descriptions

    BootBlock Size in Kbytes. 1.01 Total BIOS Size in Kbytes, including BIOS, NVRAM, BootBlock, and TotalBiosSize 1.01 any future modules that may be added. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...
  • Page 51 3 = Sharp* flash 4 = Atmel* flash 5 = Intel Firmware Hub (FWH) flash (added ver. 1.01) 6 = Intel StrataFlash™ (added ver. 1.01) 5. It is important to remember that the actual method used for write protecting the flash varies, not only between paging mechanisms, but between different boards with the same paging mechanism.
  • Page 52 The bottom of the flash drive address space would be calculated by taking the ending address of this block, subtracting the size of the flash drive, and then performing any necessary paging calculations. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 53: How To Find The System Information Structure

    The structure is designed so that any additions or changes will be backwards compatible: additional fields will be added at the end, so that the rest of the structure has the same organization as the previous version. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 54: Osflash

    ACPI, PCI local bus specification rev 2.1 and SMBIOS 1. 9.5.1 Resource Allocation The system BIOS identifies, allocates, and initializes resources in a manner consistent with other Intel servers. The BIOS scans, in order, for the following: ® Intel NetStructure...

  • Page 55: Pnp Isa Auto-Configuration

    Assigns I/O, memory, direct memory access (DMA) channels, and IRQs from the system resource pool to the embedded PnP Super I/O device. • Does not support add-in PnP ISA devices. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 56: Pci Auto-Configuration

    If the system fails to complete POST and boot an operating system, the BMC will switch to the backup BIOS (in flash) to boot, then the runtime BIOS (in flash) can be re-programmed with the flash utility. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 57: Console Redirection

    System Management BIOS (SMBIOS) The ZT 5515 follows the criteria outlined in the System Management BIOS Reference Specification, Version 2.3. Refer to this specification for details on SMBIOS. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...
  • Page 58 System BIOS This page intentionally left blank. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 59: Absolute Maximum Ratings

    Storage Temperature (no hard disk): -40° to +85° Celsius Storage Temperature (with hard disk): -40° to +65° Celsius Non-Condensing Relative Humidity: <95% at 40° Celsius ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 60: Dc Operating Characteristics

    Do not dispose of the battery in fire. When the battery is replaced, the same type or an equivalent type recommended by the manufacturer must be used. Used batteries must be disposed of according to the manufacturer's instructions. Return the board to Intel for battery service. A.1.4 Operating Temperature The ZT 5515’s heatsink allows a maximum ambient air temperature of 50°...

  • Page 61: Board Dimensions And Weight

    233.35 mm x 160 mm x 1.6 mm Board Dimensions: 6U x 4HP (one slot) Weight: 509 grams (18 ounces) w/ processor, heatsink, 512 Mbyte memory ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 62: Pcb Dimensions

    PCI Mezzanine Connector(s) (64-pin, 1 mm) page 71 page 74 IDE Connector (primary channel – local hard drive) J24, page 71 Right angle DIMM connector ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 63: Connector Locations

    COM1 Serial Port Ethernet A J11, J12, J14 PCI Mezzanine Right Angle DIMM J8 IDE J8 IDE CompactPCI Bus CompactPCI Bus Ethernet Rear-panel I/O ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 64: Backplane Connectors - Pin Locations

    14 are used for connector keying. See the “J1 CompactPCI Bus Connector Pinout” table below for pin definitions. Refer to Figure 10 for pin placement. above ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 65: J1 Compactpci Bus Connector Pinout

    J2 is a 110-pin 2 mm x 2 mm female 64-bit CompactPCI connector (AMP 352152-1). See the “J2 CompactPCI Bus Connector Pinout” table for pin definitions and Figure 10 on page 64 for pin placement. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 66: J2 Compactpci Bus Connector Pinout

    J3 is a 95-pin 2 mm x 2 mm female connector (AMP 352171-1). See the “J3 Connector Pinout” table below for pin definitions and Figure 10 on page 64 for pin placement. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 67: J3 Connector Pinout

    J5 is a 110-pin 2 mm x 2 mm female connector (AMP 352152-1) providing rear-panel user I/O. See the “J5 Rear Panel I/O Connector Pinout” table below for pin definitions and Figure 10 on page 64 for pin placement. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 68: J5 Rear Panel I/O Connector Pinout

    DRV-IRQ DD12 DD13 DD10 DD11 PBRST- DRST- Pin# IDEt COM Port ENET LED Video Power PWRGDt Floppyt Eject PS/2 SMBus Ground Misc RESV ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 69: Ja1 Ethernet A Connector Pinout

    Video signals can be directed out J5 to an RPIO board. See switch SW3-4, refer to Section 4.2.9, “SW3-4 (VGA Routing Control)” on page 32 for more information. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 70: J25 Vga Connector Pinout

    Table 30. J30 COM1 Serial Port Pinout Pin# Function Pin# Function ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 71: J11 Pci Mezzanine Connector Pinout

    B0_PAD17 B0_FRAME- B0_IRDY- B0_DEVSEL- B0_LOCK- B0_PAR VIO (VCC3) B0_PAD15 B0_PAD12 B0_PAD11 B0_PAD9 B0_CBE-0 B0_PAD6 B0_PAD5 B0_PAD4 VIO (VCC3) B0_PAD3 B0_PAD2 B0_PAD1 B0_PAD0 REQ64B ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 72: J12 Pci Mezzanine Connector Pinout

    PMC2-BUSMODE2 has a 10k pullup to VCC3. PMC2-BUSMODE3 has a 10k pulldown to GND. PMC2-BUSMODE4 has a 10k pulldown to GND. PMC2_IDSEL is connected to B0_PAD31 (PCI device 14h). ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 73: J14 Pci Mezzanine Connector Pinout

    J8 is a 44-pin, male, 2 mm (.079 inch) header (Comm Con Connectors, Inc.* 51206), providing a primary IDE channel interface. See the “J14 IDE Connector Pinout” table below for pin definitions. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 74: J8 Ide Connector Pinout

    IRQ14 IOCS16- DAP1 PDIAG DAP0 DAP2 CS1P- CS3P- PDASP CS3P- CSEL1 has 475Ω pulldown to GND. IOCS16- has 10k pullup to VCC3 (+3.3V). ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 75: Thermal Requirements

    CPU is 25 W at 1.2 GHz and 1.20 V. Caution: External airflow must be provided at all times during operation to avoid damaging the CPU. Intel strongly recommends the use of a fan tray below the card rack to supply the external airflow.
  • Page 76 Warning: Temperatures over 100° C may result in permanent damage to the processor. Refer to Table 35 on page 75 for more information ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 77: System Register Definitions

    Default Value: 0x00 Size: 8 bits Attribute: Note: This register is reset to 00h on init or reset. The BIOS resides in page 000. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 78: Flash Control (78H)

    Flash A22 (1Mbyte page) Page 1 Flash A21 (1Mbyte page) Page 0 Flash A20 (1Mbyte page) C.1.2 Watchdog (79h) I/O Address: Default Value: 0x00 Attribute: ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...
  • Page 79 010 = 1 s 110 = 128 s 011 = 8 s 111 = 256 s Power Up Value = 000. A hard reset will set these bits to 000. ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...

  • Page 80: Pal Revision Id (7Bh)

    D7 corresponds to the most significant bit. C.1.5 Switch Monitors (E3h) Address Offset: Default Value: 0x80 Size: 8 bits Attribute: ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 81: Switch Monitors (E3H)

    33). A logical 0 means that SW4-3 is open and console redirection is not enabled. A logical 1 means SW4-3 is closed and console redirection is enabled. Refer to the “Console Redirection” chapter in the Intel NetStructure Embedded BIOS Manual before attempting to use this feature.

  • Page 82: Geographic Addressing (E4H)

    Rear Panel NMI status A 1 indicates that a NMI was asserted by the rear panel. Users can write a 0 to clear this bit. RESERVED ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com...
  • Page 83 Refer to the Intel 82546EB Dual Port Gigabit Ethernet Controller datasheet for more information on the Ethernet LAN Controller. The datasheet is available from Intel's Website at: http://developer.intel.com/design/network/products/lan/controllers/82546.htm Intel 845E Chipset For more information on the following ZT 5515 functions, refer to the Intel 845E datasheet. • • Counter/Timers •...
  • Page 84 Pentium 4 Processor - M (FCPGA Package) For more information about the Intel Mobile Pentium 4 Processor - M in FCPGA Package, see the Mobile Intel Pentium 4 processor - M in FCPGA datasheet. This document is available online at: http://developer.intel.com/design/mobile/pentium4p-m/p4p-m.htm...
  • Page 85 If the product is found to be otherwise defective, Intel, at its option, will replace or repair the product at no charge except as set forth below, provided that you deliver the product along with a return material authorization (RMA) number (see below) either to the company from whom you purchased it or to Intel.
  • Page 86 Return Material Authorization (RMA) credit requests e-mail address: requests.rma@intel.com Direct Return Authorization (DRA) repair requests e-mail address: uspss.repair@intel.com DRA on-line form: http://support.intel.com/support/motherboards/draform.htm Intel Business Link (IBL): http://www.intel.com/ibl Telephone No.: 1-800-INTEL4U or 480-554-4904 Office Hours: Monday - Friday 0700-1700 MST Winter / PST Summer E.1.3 For EMEA Return Material Authorization (RMA) e-mail address - emea.fs@intel.com...
  • Page 87 If the Customer Support Group verifies that the product is defective, they will have the Direct Return Authorization/Return Material Authorization Department issue you a DRA/RMA number to place on the outer package of the product. Intel cannot accept any product without a DRA/RMA number on the package. Limitation of Liability and Remedies...
  • Page 88 Intel NetStructure product for service. Technical Support and Return for Service Assistance For all product returns and support issues, please contact your Intel product distributor or Intel Sales Representative for specific information. Sales Assistance If you have a sales question, please contact your local Intel ® NetStructure Sales Representative or the Regional Sales Office for your area.

  • Page 89: 50081-1 Emissions

    EN 55022 Class A Radiated EN 55022 Power Line Conducted Emissions EN 61000-3-2 Power Line Harmonic Emissions EN 61000-3-3 Power Line Fluctuation and Flicker ® Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification Downloaded from Elcodis.com electronic components distributor...

  • Page 90: 55024 Immunity

    1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Caution: If you make any modification to the equipment not expressly approved by Intel, you could void your authority to operate the equipment. G.4.1 Industry Canada (Canada) Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils...
