Specifications
Table 29
as implemented by the ZT 5085 midplane.
Table 29. Midplane Ethernet Connections
Switch 'A'
(Slot 2) Port
86
lists the midplane Ethernet connections from the fabric slots to the CMM and node slots
Ethernet Star 'A'
Connection
LP1 Slot 3 LPa
LP2 Slot 4 LPa
LP3 Slot 5 LPa
LP4 Slot 6 LPa
LP5 Slot 7 LPa
LP6 Slot 8 LPa
LP7 Slot 9 LPa
LP8 Slot 10 LPa
LP9 Slot 11 LPa
LP10 Slot 12 LPa
LP11 Slot 13 LPa
LP12 Slot 14 LPa
LP13 Slot 15 LPa
LP14 Slot 16 LPa
LP15 Slot 17 LPa
LP16 Slot 18 LPa
LP17 Slot 19 LPa
LP18 Slot 20 LPa
LP19 CMM 'A'
Switch 'B'
LPf
(Slot 21) LPf
Ethernet Star 'B'
Switch 'B'
Connection
(Slot 21) Port
LP1 Slot 3 LPb
LP2 Slot 4 LPb
LP3 Slot 5 LPb
LP4 Slot 6 LPb
LP5 Slot 7 LPb
LP6 Slot 8 LPb
LP7 Slot 9 LPb
LP8 Slot 10 LPb
LP9 Slot 11 LPb
LP10 Slot 12 LPb
LP11 Slot 13 LPb
LP12 Slot 14 LPb
LP13 Slot 15 LPb
LP14 Slot 16 LPb
LP15 Slot 17 LPb
LP16 Slot 18 LPb
LP17 Slot 19 LPb
LP18 Slot 20 LPb
LP19 CMM 'B'
Switch 'A'
LPf
(slot 2) LPf
