Power Subsystem
Figure 22. ZT 5085 Power Distribution Overview (DC System)
4.1.1

DC Systems

There are twofour redundant DC power feeds:. A and B. Each DC power feed provides input to
two power supplies in each of the two power trays. Feed A provides power to the odd numbered
power supplies while Feed B provides power to the even numbered power supplies.
This configuration provides 2+2 redundant power to DC systemseach power domain.
4.2

DC System Redundancy

The system is designed to continue operation with any single fault. Examples of faults include:
•
Power feed failure
•
Power supply failure
If a single power feed fails, the system continues to receive power from the four power supplies
powered from the healthy feed. If a single power supply fails, the system continues to receive
adequate power from the healthy power supplies.
