Getting Started
Table 1. V(I/O) Related Slot Capabilities
V(I/O)
3.3 V
5 V
Not all V(I/O) planes need to be configured for the same level. It is valid to have some V(I/O)
planes set to 3.3 V while others are set to 5 V.
M66EN jumper settings required for different V(I/O) levels on each V(I/O) plane.
Warning: It is critical that each V(I/O) plane does not have both its 3.3 V and 5 V shunts loaded
simultaneously. Doing so causes permanent damage to the midplane and could pose a fire hazard.
Table 2. V(I/O) Configuration Options
V(I/O) Plane
Fabric A
CompactPCI*
Segment 1
CompactPCI*
Segment 2
PCI-Less
Fabric B
Figure 14 on page 31
30
Universal Voltage
66 MHz Operation
No Yes
No Yes
Slot(s) V(I/O) Setting
3.3 V
2
5 V (Default)
3.3 V
3-9
and 11
5 V (Default)
3.3 V
10
and 12-18
5 V (Default)
3.3 V
19 and 20
5 V (Default)
3.3 V
21
5 V (Default)
shows the locations of the V(I/O) shunts and the M66EN jumpers.
3.3 V Boards
Boards
Yes
No
Table 1 lists the V(I/O) shunts (Bolts), P1 keys, and
V(I/O) Shunt
V(I/O)A 3.3 V Position
V(I/O)A 5 V Position
V(I/O)B 3.3 V Position
V(I/O)B 5 V Position
V(I/O)C 3.3 V Position
V(I/O)C 5 V Position
V(I/O)D 3.3 V Position
V(I/O)D 5 V Position
V(I/O)F 3.3 V Position
V(I/O)F 5 V Position
5 V Boards
No
Yes
P1 Key Color
Cadmium Yellow
Brilliant Blue
Cadmium Yellow
Brilliant Blue
Cadmium Yellow
Brilliant Blue
Cadmium Yellow
Brilliant Blue
Cadmium Yellow
Brilliant Blue
