Cooling Subsystem
The ZT 5085 utilizes three hot swappable fan trays to cool the chassis. Each fan tray includes three
blowers.
Figure 25. Airflow
AIR LOW
ront Grill
with ilter
* Other names and brands may be claimed as the property of others.
5.1
Fan Trays
Each of the ZT 5085's three fan trays is a modular, field replaceable unit. Each tray contains three
blowers, a control board, and a status LED. These features are discussed in the following sections.
For information about working with fan trays refer to
page
42.
Technical Product Specification
Figure 25
illustrates the airflow through the platform.
ront
Comair*
Blower
3 Blowers per an Tray
Comair
Blower
Delta* Blower
Power
Supply
Section 3.4, "Working with Fan Trays" on
Cooling Subsystem
5
Rear
Mid
plane
Power
plane
3280-03
55
