Labconco Logic+ A2 Technical Manual page 61

Type B2
Height
Cabinet Width
(inches)
4-foot
6-foot
1. The calculated concentration was established using the formula:
Concentration (ug/l) = (# Laskin nozzles @ 23 PSIG x 13,500) / Volume of air displaced
2. Based on Mineral oil
Figure 10-9
Sash Supply Air
Displacement
(CFM)
8 445
8 665
Place aerosol
generator here
Pre-Filter
Laskin Calculated
Nozzles Concentration
Required
1
1
61
Figure 10-10
Thumbnuts (2)
Table 10-2
Actual
Concentration
1 (ug/L)
(ug/L)
30 15
20 12
2
