Page 1 EEDEN07-201 technical data VAM-FA8VE VKM-GAMV1 VKM-GAV1...
Page 3: Table Of Contents
TABLE OF CONTENTS Part 1: VAM-FA8VE ..............3 External appearance .
Page 4 • HRV TABLE OF CONTENTS Operation ............204 Installation .
Page 5: Part 1: Vam-Fa8Ve
• HRV • VAM-FA8VE TABLE OF CONTENTS Part 1: VAM-FA8VE External appearance ..........5 Model series .
Page 6 • HRV • VAM-FA8VE TABLE OF CONTENTS Part 1: VAM-FA8VE Pre -Operation flowchart ......... . . 135 Operation mode change over .
Page 7: External Appearance
• HRV • VAM-FA8VE External appearance VAM150FA8VE VAM250FA8VE VAM350FA8VE VAM500FA8VE VAM650FA8VE VAM800FA8VE VAM1000FA8VE VAM1500FA8VE VAM2000FA8VE Model series VAM150FA8VE VAM250FA8VE VAM350FA8VE VAM500FA8VE VAM650FA8VE VAM800FA8VE VAM1000FA8VE VAM1500FA8VE VAM2000FA8VE Nomenclature V A M F A VE Ventilation Mounted type Air flow rate (m...
Page 8: Structures
• HRV • VAM-FA8VE Structures VAM150-1000FA Heat exchange elements Ceiling hock Maintenance cover (Outdoor air) [Fresh air from outdoor] (Exhaust air) [Exhaust air to outdoor] Switch box Duct connection flange Exhaust fan Name plate Air filter (Long life filter) (Supply air)
Page 9: Features
• HRV • VAM-FA8VE Features Interlocked operation with VRV (SkyAir) 1. Simultaneous ON / OFF with the indoor unit by the indoor unit remote control. 2. HRV independent operation during air conditioning off season by the indoor unit remote control.
Page 10: Energy Saving
• HRV • VAM-FA8VE Features Energy Saving HRV unit recovers the thermal energy during cooling / heating operation of air conditioner. HRV reduces the cooling / heating load drastically and enhances the By heat recovery operation heating / cooling efficiency.
Page 11: Fresh-Up Operation
• HRV • VAM-FA8VE Features FRESH-UP operation Both the excessive supply mode and the excessive exhaust mode are selectable. This function creates a more comfortable air environment. Supply Fresh-up Exhaust Fresh-up (Excessive outdoor air supply) (Excessive Exhaust air supply) Supply air volume can be set at a higher level than the...
Page 12: Easy Installation And Service Maintenance
• HRV • VAM-FA8VE Features Easy Installation and service maintenance Downsized Total volume is reduced to 68% of EJ series and the unit fits into a small space. (Comparison with FJ and previous EJ series) Height Height Difference Volume compared with...
Page 13: Selection Procedures
• HRV • VAM-FA8VE Selection Procedures Various methods are used to calculate the required ventilating airflow rate according to CO generated by inhabitants in a room, waste gas generated by use of fire, and other conditions of a room. Here are 2 patterns of calculating methods.
Page 14 • HRV • VAM-FA8VE Selection Procedures Based on Room size <Table 3> Criteria for Model Selection Required Frequency Air Flow Rate Area per person ventilating AFR Model Name Application area (m per person / person) / h / person) 16.5 –...
Page 15 • HRV • VAM-FA8VE Selection Procedures Based on Room size Required Frequency Air Flow Rate Area per person ventilating AFR Model Name Application area (m per person / person) / h / person) – 11.3 VAM 150FA – 11.3 11.6 –...
Page 16: Product Specification
• HRV • VAM-FA8VE Product Specification Specifications 7-1-1 Technical specifications (50Hz) Model name VAM150FA VAM250FA VAM350FA Power supply Single phase 220 – 240 V / 50Hz Ultra-High Temperature exchanging efficiency High Ultra-High Cooling High Enthalpy exchange efficiency Ultra-High Heating High...
Page 17 • HRV • VAM-FA8VE Product Specification Specifications 7-1-1 Technical specifications (50Hz) Model name VAM500FA VAM650FA Power supply Single phase 220 – 240 V / 50Hz Ultra-High Temperature exchanging efficiency High Ultra-High Cooling High Enthalpy exchange efficiency Ultra-High Heating High Ultra-high...
Page 18 • HRV • VAM-FA8VE Product Specification Specifications 7-1-1 Technical specifications (50Hz) Model name VAM800FA VAM1000FA VAM1500FA VAM2000FA Power supply Single phase 220 – 240 V / 220 V, 50 / 60 Hz Ultra-High Temperature exchanging efficiency High 76.5 Ultra-High Cooling...
Page 19 • HRV • VAM-FA8VE Product Specification Specifications 7-1-1 Technical specifications Test conditions are as follows Indoor unit Outdoor unit Condition °CDB °CDB R·H (%) R·H (%) Cooling condition Heating condition Notes: 1. Operation sound is measured at 1.5 m below the center the body.
Page 20 • HRV • VAM-FA8VE Product Specification Specifications 7-1-2 Electrical specifications Units Power supply Model name 50Hz 60Hz 0.03 × 2 0.4 × 2 VAM150FA 0.03 × 2 0.4 × 2 VAM250FA 0.03 × 2 0.6 × 2 VAM350FA 1.35 0.03 × 2 0.6 ×...
Page 21: Optional Accessories
• HRV • VAM-FA8VE Product Specification Optional accessories Installation example • HRV • Heat Reclaim Ventilation...
Page 22 • HRV • VAM-FA8VE Product Specification Optional accessories Optional Accesories Model VAM150FA VAM250FA VAM350FA VAM500FA VAM650FA Item Remote control BRC301B61 Wired remote controller BRC1D52 Central remote control DCS302C51 (for general) DCS302C51 (For EC market) Centralized controlling Unified On/Off control DCS301B61 (for general) DCS301B51 (For EC market)
Page 23 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-1 BRC301B61: Remote control 7-2-1-1 Remote control mounting instructions 1. Remove the upper part of remote control. Insert minus screwdriver into the slots in the lower part of remote controller (2 places), and remove the upper part of remote control.
Page 24 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-1 BRC301B61: Remote control 7-2-1-1 Remote control mounting instructions 3. Wire the HRV unit. NOTE Connect the terminals on the upper part of the When wiring, run the wiring away the remote...
Page 25 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-2 KRP50-2: Wiring adapter for remote contact / Humidifier KRP50-2A90: Installation box for adapter PCB Components 2 KRP50-2 can also be connected to SkyAir indoor unit for the interlocked operation with HRV units. Or to be connected 1.
Page 26 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices KRP2A51 (For Europe) KRP2A61 (For General) Accessories Check the following accessories are included in the kit before the installation. Wiring Adapter for Electrical Appendices (1) ×...
Page 27 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices Indoor unit To host computer monitor panel etc. Max. 16 unit Remote controller Max. 64 groups Max. 16 unit To outdoor unit Notes: Individual indoor units connected to the centralized line cannot be displayed individually.
Page 28 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices Installation Ceiling mounted corner cassette Adapter (KRP2A61 KRP2A51) Electric parts box PCB support P board ass’y (HC0118) 4-way blow ceiling mounted cassette Lid of PCB Box...
Page 29 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices 2-way blow ceiling mounted cassette Box for adapter PCB (Option KRP1C98) Electric parts box Installation screw PCB support Adapter P board ass’y • (KRP2A61...
Page 30 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices Concealed ceiling unit (large) 40-125 200 • 250 PCB support Adapter (KRP2A61 • 51) Adapter (KRP2A61) Indoor PC board P board ass’y PCB support...
Page 31 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices (Concealed) floor standing unit P board ass’y PCB support Electric parts box Adapter (KRP2A61 • 51) (HC0250) Electrical wiring 1. First, wire between the indoor and outdoor units, then to the separate power sources, and between the indoor units and the remote controllers.
Page 32 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices Wiring to indoor units 1. For zone control Be sure to set to “ZONE” X18A PC board ass’y DISPLAY OUTPUT Adapter P1,P2 F1,F2 P1,P2...
Page 33 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices Wiring to external units (host computer monitor panel) 1. Remote control input (operation control) Wire as described below. Wiring differs depending on whether using a voltage or non-voltage input.
Page 34 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices 2. Setting control mode selector sitch (RS1) Using control mode selector switch (RS1), select the control mode as described below. Factory set: “0” position 1.
Page 35 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices • For demand control from input B Position Function when input A is ON Function when input B is ON Forced thermostat OFF command Remote controller rejected (Same as position “5”)
Page 36 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices 3. Temperature setting input To enable temperature setting from both the adapter and remote controller, set SS2 to “P”. (Factory set: P) P: Enables temperature setting by both the adapter and remote controller.
Page 37 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-3 KRP2A51, KRP2A61: Wiring adapter for electrical appendices 4. Cancelling display signals Operation output terminals (W1 and W2) and malfunction output terminals (W3 and W4) are non-voltage constant contact output. (Allowed electric current per contact is between 10 mA and 3A.)
Page 38 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-4 KRP1B61: Interlock adapter of VRV Accessories Check if the following accessories are included in the kit. Adapter × 4 PC board support × 3 Clamp × 1 Installation manual (HC0129) •...
Page 39 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-4 KRP1B61: Interlock adapter of VRV Electric Wiring • Refer to the WIRING DIAGRAM attached to the indoor unit before attempting to wire. [Make sure wires to units do not pass over the PC board when wiring.] •...
Page 40 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-4 KRP1B61: Interlock adapter of VRV Installation • Installation differs according to models. • Do not bundle low and high voltage wires together. • Bundle any access wires with the attached clamps so as to keep loose wirings off the indoor unit PC board.
Page 41 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-4 KRP1B61: Interlock adapter of VRV Concealed ceiling unit (large) 40 ~ 125 200 ~ 250 Indoor PC board Electric parts box Adapter Indoor PC board (KRP1B61) PCB support PCB support Adapter...
Page 42 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-5 KRP1B2: Interlock adapter of VRV Contents of kit Prior to installation check whether you have the complete kit of parts as shown below including the installation manual. PC board support 4 pieces...
Page 43 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-5 KRP1B2: Interlock adapter of VRV Electrical wiring • Refer to the wiring diagram of the indoor unit for it’s wiring connection. (Make sure all the wiring to the unit should not go over the PC board.) •...
Page 44 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-6 KRP1B3: Interlock adapter of VRV Contents of kit Prior to installation check whether you have the complete kit of parts as shown below including the installation manual. Adapter PCB Plastic strap...
Page 45 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-6 KRP1B3: Interlock adapter of VRV Electrical wiring • Refer to the wiring diagram of the indoor unit for its wiring connection. (Make sure all the wiring to the unit should not go over the PC board.) •...
Page 46 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control • When using 1 central remote controller • When using 2 central remote controllers BEFORE USE: GENERAL DESCRIPTION OF SYSTEM For a maximum of 64 groups of indoor unit unified operation/stop can be performed. When using 2 central remote controllers, unified operation is possible with up to a maximum of 128 groups of indoor units.
Page 47 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control GROUP OF INDOOR UNIT refers to the above. A: A single indoor unit without remote controller B: A single indoor unit controlled by one or two remote controllers...
Page 48 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control Fig.1 A L L A L L • • • CENTRAL REMOTE CONTROLLER • • • • • • • • • • • REF. • ZONE ZONE...
Page 49 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control A L L A L L CENTRAL REM OTE CONTROLLER ZONE ZONE Fig. 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 ·...
Page 50 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control A L L A L L CENTRAL REM OTE CONTROLLER MONITOR Fig. GROUP 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15...
Page 51 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control A L L A L L CENTRAL REM OTE CONTROLLER Fig. MONITOR GROUP 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15...
Page 52 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control FEATURES AND FUNCTIONS Operation menu This central remote controller enables the individual operation/stop See page by zone, and unified operation/stop. ON/OFF operation controlled by 54, 63 timer is possible in conjunction with the schedule timer (optional accessory).
Page 53 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control NAMES AND FUNCTIONS OF THE OPERATING SECTION (Fig. 1,2) “ ” DISPLAY (TIME NO.) UNIFIED OPERATION BUTTON Displays the operation timer No. when used in Press to operate all indoor units.
Page 54 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control “ ” “ ” DISPLAY TEMPERATURE SETTING BUTTON (TIME TO CLEAN AIR CLEANER ELEMENT/TIME TO CLEAN AIR FILTER) Displayed to notify the user it is time to clean the air Press to set temperature.
Page 55 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control Press the ZONE SETTING BUTTON again, to finish ZONE SETTING (Fig. 3) zoning. The current display goes out, and the normal display appears. You can set multiple groups under a single zone to control them by zone.
Page 56 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control OPERATION Press the TIMER ON BUTTON. Press the TIMER ON BUTTON within 10 seconds after the code No. is displayed. The display stops flashing and lights OPERATION BY ZONE (Fig. 4) up solidly.
Page 57 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control Cooling mode is selected. Unified operation is not set within the zone. Press the TEMPERATURE SETTING BUTTON. Each time you press the “ ”, the temperature rises by 1 C.
Page 58 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control OPERATION MODE The following five operation control modes can be selected along with the temperature setting and operation mode by remote controller, for a total of twenty different modes. These twenty modes are set and displayed with control modes of 0 to 19. (For further details, see EXAMPLE OF OPERATION SCHEDULE on the next page.)
Page 59 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control Control by remote controller Operation Unified operation, Unified stop, individual stop by Operation mode central remote controller, or Control mode individual operation timer stop by central remote Temperature...
Page 60 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control ON/OFF control possible by remote controller Operation Operation Timer stops even Centralized controlled if you forget to controlled SET1 by timer turn off the unit. by timer Programmed...
Page 61 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control • List of setting operation SETTING OPERATION MODE A: Zones not displayed (Fig. 5) Display Setting Contents of setting • The Zone consists of the following two cases.
Page 62 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control TEMPERATURE SETTING GROUP MONITORING (Fig. 6) (Fig. 7) Utilize the group monitor function in each of the Press the TEMPERATURE SETTING BUTTON. following cases: Each time you press the “...
Page 63 Check the contents of the display, and contact controller. your DAIKIN dealer because the above signs can give you the idea on the trouble area. • Check the particular group with the master remote The display “...
Page 64 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control FUNCTION OF REFRIGERANT DISPLAY OF TIME TO CLEAN SYSTEM DISPLAY (Fig. 10) (Fig. 11) The following information becomes available by utilizing this This central remote controller displays the time to clean the air function.
Page 65 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control UNIFIED OPERATION (Fig. 12) Use this function when executing operation and stop of all the connected indoor units. Unified operation Press the UNIFIED OPERATION BUTTON. All the displays “...
Page 66 You can perform the normal operation, take off the malfunction contact point and unified operation/stop by contact point, all by connecting this unit with the unification adapter for computerized control. For further details, ask your DAIKIN dealer. Unification adapter for computerized control...
Page 67 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-7 DCS302C51: Centralized control SPECIFICATIONS Specifications Power supply Single phase, 50 / 60 Hz, 220 – 240 V / 220 V Power consumption Max. 4.5 W Continuous “a” contact Forced ON / OFF input...
Page 68 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-8 DCS301B61: Unified ON / OFF control NAMES AND FUNCTIONS UNIFIED OPERATION/STOP BUTTON “UNDER HOST COMPUTER Starts/stops all indoor units. INTEGRATED CONTROL” When this lamp turns on, no other operations are possible.
Page 69 • When used in conjunction with central remote controller, the control modes of the central remote controller has the priority. DISPLAY OF MALFUNCTION Flashing of lamps indicates malfunctions. Contact your Daikin dealer. When turning power supply on, all lamps may light and UNDER HOST COMPUTER INTEGRATED CONTROL lamp may flash and not accept the operation for about one minute.
Page 70 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer CAUTIONS DURING USE • Do not tamper with the inner mechanism. Do not remove the front panel. Tampering with the inner mechanism is dangerous and may damage equipment. For inspection and adjustment, contact your DAIKIN dealer.
Page 71 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer Fig.1 • • • SCHEDULE TIMER • • PROGRAM START SET 1 • • OFF OFF OFF OFF OFF OFF OFF AM PM AM PM • MON TUE WED THU FRI SAT SUN •...
Page 72 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer SCHEDULE TIMER SCHEDULE TIMER SET 1 SET 1 OFF OFF OFF OFF Fig. Fig. SAT SUN SAT SUN SET 2 SET 2 AM PM CLOCK CLOCK PROGRAM PROGRAM MIN.
Page 73 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer NAMES AND FUNCTIONS OF THE OPERATING SECTION (Fig. 1,2) AM PM DISPLAY “ ” (PROGRAMMED TIME OF UNIFIED OPERATION BUTTON SYSTEM OFF) Press this button to perform the unified operation Displays the time programmed to stop.
Page 74 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer OPERATION SETTING PRESENT Set the time to TIME (Fig. 3) CLOCK 5:30 p.m.. (Example) In case of setting Friday, 5:30 p.m. Press the TIMER ON BUTTON the moment the time signal of TV, radio, telephone, etc.
Page 75 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer minute and hour by hour. When the button is kept pressed, SETTING NO. OF the display is put forward continuously. PROGRAMMED TIME (Fig. 4) Set the PROGRAM START...
Page 76 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer Press the PROGRAMMING START BUTTON, and finish CHANGE AND CANCELLATION the program setting. OF NO. OF PROGRAMMED Notes: • Unless the button is pressed within 20 minutes, the display TIME (Fig.
Page 77 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer A. Change/cancel partially B. Cancel the whole Press OK button if you do not want to change the Press the BUTTON FOR SELECTING DAYS OF A WEEK, and timer on.
Page 78 OPERATION LAMP turns on. communication with the indoor unit. Check the contents of the display and contact your DAIKIN dealer because the signals give you the idea of the trouble area. Press the UNIFIED STOP BUTTON, and the OPERATION LAMP is turned off.
Page 79 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-9 DST301B61: Schedule timer SPECIFICATION SPECIFICATIONS Display of time 12-hour digital display Clock cycle type Quartz clock type Clock accuracy Within • 30 sec. / month (environmental temperature from 15 C to 35 C)
Page 80 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-10 K-DGL100A, K-DGL150A, K-DGL200A, K-DGL250A: Air suction / discharge grill Model name K-DGL100A K-DGL150A K-DGL200A K-DGL250A VAM150FA VAM250FA VAM500FA VAM 800FA VAM350FA VAM650FA VAM1000FA Applicable model VAM1500FA VAM2000FA φ 100 φ 150 φ...
Page 81 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-10 K-DGL100A, K-DGL150A, K-DGL200A, K-DGL250A: Air suction / discharge grill Dimensions K-DGL100A K-DGL150A 300 (Hook hole pitch) 350 (Hook hole pitch) 8 – 5.5 × 9.5 slot 8 – 5.5 × 9.5 slot...
Page 82 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-10 K-DGL100A, K-DGL150A, K-DGL200A, K-DGL250A: Air suction / discharge grill Installation procedure Before starting installation, attach the supplied packing to the adapter provided in the same package. (Attach the packing to the adapter flange so that it will be set within the periphery of the flange.)
Page 83 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-10 K-DGL100A, K-DGL150A, K-DGL200A, K-DGL250A: Air suction / discharge grill Common works Installing the ceiling material and gluing the wall paper Duct connection and ceiling board installation For installing the ceiling material 1.
Page 84 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-11 KDDM24A50, KDDM24A100: Silencer Part No. KDDM24A50 KDDM24A100 VAM800FA, VAM1000FA, Applicable model VAM500FA VAM650FA VAM1500FA, VAM2000FA φ 200 mm φ 200 mm φ 250 mm Nominal pipe diameter Noice suppression effect Approx. 6 dB...
Page 85 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-12 YAFF323F15, YAFF323F25, YAFF323F35,YAFF323F50, YAFF323F65, YAFF323F100: Air filter replacement Dimension Part No. Applicable model Q’ty YAFF323F15 VAM150FA YAFF323F25 VAM250FA YAFF323F35 VAM350FA YAFF323F50 VAM500FA VAM650FA, VAM800FA YAFF323F65 VAM1500FA VAM1000FA YAFF323F100 VAM2000FA Specification Dimension table [mm] Working ambient temperature –...
Page 86 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-14 K-FDS101C, K-FDS151C, K-FDS201C, K-FDS251C, K-FDS102C, K-FDS152C, K-FDS202C, K-FDS252C: Flexible Duct Part Name: 1 m K-FDS101C K-FDS151C K-FDS201C K-FDS251C Part Name: 2 m K-FDS102C K-FDS152C K-FDS202C K-FDS252C VAM150FA VAM250FA VAM500FA VAM 800FA...
Page 87 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-16 BRP4A50: Heater control kit Operation range of the HRV is “ –10 C to 50 CDB 80% RH or below.” When operating the HRV units at or below –10 C of the outdoor air temperature, use preheater (field supplied) to preheat outdoor air.
Page 88 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-16 BRP4A50: Heater control kit Installation example Exhaust Air Return Air Outdoor Air Preheater Supply Ai (Field supply) Adapter BRP4A50 Temperature thermostat (Field supply) (Heater ON when the temperature is at or below –...
Page 89 • HRV • VAM-FA8VE Product Specification Optional accessories 7-2-16 BRP4A50: Heater control kit Heater control kit Accessories Fixing Screw 2 pcs. See the right for componens. Clamp 2 pcs. Installation Install the Heater control kit to the outside of switch box for HRV unit as shown below.
Page 90: The Correction Ratio Of Exchange Efficiency
• HRV • VAM-FA8VE Product Specification) The correction ratio of exchange efficiency Exchange efficiency less than 50% Supply air flow rate / exhaust air flow rate C: 4D023764 + 4D023764 <Example of correction> VAM500 (50Hz): Air flow rate at strong notch 500 m...
Page 91: Dimensions
• HRV • VAM-FA8VE Product Specification) Dimensions VAM150FA Maintenance space for the heat exchange elements, the air filters and fans Switch box Ceiling hook Inspection hole 4-14x40 oval hole Supply air fan Maintenance cover Supply air to room Fresh air from outdoors...
Page 92 • HRV • VAM-FA8VE Product Specification) Dimensions VAM350FA Maintenance space for the heat exchange elements, the air filters and fans Switch box Ceiling hook Inspection hole 4-14x40 oval hole Supply air fan Maintenance cover Fresh air from outdoors (Outdoor air)
Page 93 • HRV • VAM-FA8VE Product Specification) Dimensions VAM650FA Maintenance space for the heat exchange elements, the air filters and fans Switch box Ceiling hook Inspection hole 4-14x40 oval hole Supply air fan Maintenance cover Fresh air from outdoors Supply air to room...
Page 94 • HRV • VAM-FA8VE Product Specification) Dimensions VAM1000FA Maintenance space for the heat Switch box exchange elements, the air filters and fans Ceiling hook Inspection 4-14X40 oval hole hole Supply air fan Maintenance cover Fresh air from outdoor Supply air...
Page 95 • HRV • VAM-FA8VE Product Specification) Dimensions VAM2000FA Maintenance space for the heat Switch box exchange elements, the air filters and fans Inspection Ceiling hook hole 4-14X40 oval hole Supply air fan (2 pieces) Maintenance cover Fresh air from Supply air...
Page 96: Wiring Diagram
• HRV • VAM-FA8VE Product Specification) Wiring diagram VAM150-1000FA Wiring diagram Power supply single phase 220-240/220V 50/60Hz External output terminals Adapter for wiring (optionl accessories) (KRP50-2) Switch box Terminals for the input from outside Terminals for the centralized control Remote control...
Page 97 • HRV • VAM-FA8VE Product Specification) Wiring diagram VAM1500,2000FA Wiring diagram Power supply Single phase 220-240/220V Adapter for wiring (optional accesories) 50/60Hz (KRP50-2) External output terminals Terminals for the input from outside Terminals for the centralized control Remote control (optional accessories)
Page 98: Sound Level Data
• HRV • VAM-FA8VE Product Specification) Sound level data 7-6-1 Overall sound pressure levels 220V / 50Hz 230V / 50Hz Total Heat Total Heat Bypass mode Bypass mode Ventilation Mode Exchange mode Exchange mode Fan Speed VAM150FA 20.5 26.5 20.5 VAM250FA 27.5...
Page 99 • HRV • VAM-FA8VE Product Specification) Sound level data 7-6-2 Sound power spectrum VAM150FA VAM250FA [dB] [dB] Model Power supply 1000 2000 4000 8000 Model Power supply 1000 2000 4000 8000 Notch Notch 40.5 38.5 25.5 51.1 38.5 33.5 25.5 25.5...
Page 100 • HRV • VAM-FA8VE Product Specification) Sound level data 7-6-2 Sound power spectrum VAM800FA VAM1000FA [dB] [dB] Model Power supply 1000 2000 4000 8000 Model Power supply 1000 2000 4000 8000 Notch Notch 52.5 49.5 48.5 41.5 33.5 58.5 50.5 36.5...
Page 101 • HRV • VAM-FA8VE Product Specification) Sound level data 7-6-3 Sound pressure spectrum VAM150FA VAM250FA VAM350FA Approximate Approximate Approximate threshold hearing threshold hearing threshold hearing for continuous for continuous for continuous noise noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 102 • HRV • VAM-FA8VE Product Specification) Sound level data 7-6-3 Sound pressure spectrum VAM500FA VAM650FA VAM800FA Approximate Approximate Approximate threshold hearing threshold hearing threshold hearing for continuous for continuous for continuous noise noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 103 • HRV • VAM-FA8VE Product Specification) Sound level data 7-6-3 Sound pressure spectrum VAM1000FA VAM1500FA VAM2000FA Approximate Approximate Approximate threshold hearing threshold hearing threshold hearing for continuous noise for continuous noise for continuous noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 104: Fan Performance
• HRV • VAM-FA8VE Product Specification) Fan performance VAM150FA VAM250FA Exchange efficiency Exchange efficiency VAM150FAVE VAM250FAVE Ultra-High Ultra-High High ø 150 High Pipe length ø 100 Pipe length Air flow rate (m / h) Air flow rate (m / h)
Page 105 • HRV • VAM-FA8VE Product Specification) Fan performance VAM800FA VAM1000FA Exchange efficiency Exchange efficiency VAM800FA5VE VAM1000FA5VE Ultra-High ø 250 High Pipe Ultra-High length ø 250 Pipe length High Air flow rate (m / h) Air flow rate (m / h)
Page 106: Installation Method
• HRV • VAM-FA8VE Product Specification) Installation method VAM150FA MAINTENANCE SPACE SUSPENSION BOLT POSITION INSPECTION HOLE AIR DISCHARGE GRILLE K-DGL100A (FRESH AIR FROM OUTDOORS) VAM150FA HEAT INSULATOR ROUND SHAPE HOOD (FIELD SUPPLY) (FIELD SUPPLY) (EXHAUST AIR TO OUTDOORS) AIR SUCTION GRILLE...
Page 107 • HRV • VAM-FA8VE Product Specification) Installation method VAM350FA MAINTENANCE SPACE INSPECTION HOLE SUSPENSION AIR DISCHARGE BOLT POSITION GRILLE K-DGL150A (FRESH AIR FROM OUTDOORS) ROUND SHAPE HOOD HEAT INSULATOR (FIELD SUPPLY) VAM350FA (FIELD SUPPLY) (EXHAUST AIR TO OUTDOORS) AIR SUCTION GRILLE...
Page 108 • HRV • VAM-FA8VE Product Specification) Installation method VAM650FA MAINTENANCE SPACE INSPECTION HOLE (FRESH AIR FROM OUTDOORS) HEAT INSULATOR ROUND SHAPE HOOD VAM650FA (FIELD SUPPLY) (FIELD SUPPLY) AIR DISCHARGE (EXHAUST AIR TO OUTDOORS SUSPENSION GRILLE BOLT POSITION K-DGL200A AIR SUCTION GRILLE...
Page 109 • HRV • VAM-FA8VE Product Specification) Installation method VAM1000FA MAINTENANCE SPACE INSPECTION AIR DISCHARGE HOLE SUSPENSION GRILLE BOLT POSITION K-DGL200A SILENCER KDDM24A100 (FRESH AIR FROM FLEXIBLE DUCT OUTDOORS) K-FDS252C ROUND SHAPE HOOD HEAT INSULATOR (FIELD SUPPLY) (FIELD SUPPLY) SUSPENSION VAM1000FA...
Page 110 • HRV • VAM-FA8VE Product Specification) Installation method VAM2000FA Maintenance space Air discharge grille Suspension bolt position Suspension bolt Inspection Silencer position hole Flexible duct Maintenance space Round shape hood Field supply Branch duct EA (Exhaust air to outdoors) Nominal diameter...
Page 111: Operation
• HRV • VAM-FA8VE Operation Method of operation 8-1-1 Operation with the remote control exclusively for Air conditioning operation HRV units. (BRC301B61) For non-independent systems, starting / stopping operation and timer operation may not be possible. Use the air conditioner remote control or the Centralized control in such cases.
Page 112 • HRV • VAM-FA8VE Operation Method of operation 8-1-2 Operating the HRV unit using the remote control of the VRV- system air conditioner When the VRV-system air conditioner is connected with the HRV unit with a direct duct, the remote control of the air conditioner cannot be used to select the VENTILATION mode.
Page 113: Cautions In Use
• HRV • VAM-FA8VE Operation Cautions in use Maintenance (for a qualified service person only) WARNING Never inspect or service the unit by yourself. CAUTION Ask a qualified service person to perform this work. Only a qualified service person is allowed to perform (The qualified service person) maintenance.
Page 114: Trouble Shooting
• HRV • VAM-FA8VE Operation Maintenance CAUTION 1. Do not wash the air filter in hot water. 2. Do not dry the air filter over a fire. The air filter is an optional item and the replacement is available. 3. Do not subject the air filter to direct sunlight.
Page 115: Control System
• HRV • VAM-FA8VE Control System Introduction of control system The control systems introduced here is for the HRV unit adopting the high speed and high performance transmission system (DIII-NET), the same as the VRV systems and SkyAir series, Description of system...
Page 116: Basic Patterns
• HRV • VAM-FA8VE Control System Basic patterns 9-2-1 List of control system Control Purposes and applications Description of system Optional accessories required system BRC301B61 • Basic method to operate HRV unit The remote controller for HRV unit is Liquid crystal remote controller installed on each HRV unit for its operation.
Page 117 • HRV • VAM-FA8VE Function Nos. of the unit controlled and length of wiring Cautions page BRC301B61 • One remote controller operates each HRV unit. • The wire for remote controller is not included as standard accessories and should be arranged locally.
Page 118 • HRV • VAM-FA8VE Control System Basic patterns Control Optional accessories Purposes and applications Description of system system required • When the HRV unit is interlocked to 2 KRP2A61 ♦Adapter PCB for or more groups of indoor units, The Central transmission line...
Page 119 • HRV • VAM-FA8VE Function Nos. of the unit controlled and length of wiring Cautions page • The HRV unit operates of one of the indoor units • A maximum of 64 groups of the units can be • No direct duct connection is possible.
Page 120 • HRV • VAM-FA8VE Control System Basic patterns 9-2-2 Independent system Operation by main switch Purposes and functions Switch setting of HRV unit • Basic method to operate HRV unit • No change is required. (as per factory setting) The remote control for HRV unit is installed on each HRV Optional accessories required unit for its operation.
Page 121 • HRV • VAM-FA8VE Control System Basic patterns 9-2-2 Independent system Control with two remote controls Purpose and functions Example of wiring for control • For control of one HRV unit (Also one group control is possible) J1 J2 F1 F2...
Page 122 • HRV • VAM-FA8VE Control System Basic patterns 9-2-3 The interlocked operation system Single-group interlocked operation (Basic pattern) Purposes and functions Example of control wiring • The remote control for indoor unit can control the interlocked operation with the HRV unit, and it can make...
Page 123 • HRV • VAM-FA8VE Control System Basic patterns 9-2-3 The interlocked operation system Interlocked operation with 2 or more group of VRV system Purposes and functions Example of control wiring • When the HRV unit is interlocked to 2 or more group of...
Page 124 • HRV • VAM-FA8VE Control System Basic patterns 9-2-4 Centralized control system Collective / individual control [Unified On / Off control DCS301B61] Purposes and functions Example of control wiring • One control can control the operation of Unified “ON / OFF” of 16 groups of the units collectively or...
Page 125 • HRV • VAM-FA8VE Control System Basic patterns 9-2-4 Centralized control system Zone control system (Central remote control DCS302B61) Purposes and functions Example of control wiring • A maximum of 64 groups can be controlled On / Off individually by one control. And also the central...
Page 126: Applicable Patterns
• HRV • VAM-FA8VE Control System Applicable patterns 9-3-1 Additional functions Operation by power supply [HRV unit] Purposes and functions Example of control wiring • The HRV unit is operated by “On / Off” of the main power breaker. This is possible only for the independent...
Page 127 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-1 Additional functions Fresh-up operation by external input [HRV unit] Purposes and functions Example of control wiring When the operation is interlocked with the local ventilating fan (such as the one for toilet or kitchen), the HRV unit Connecting line can be extended up to 50 m maximum.
Page 128 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-1 Additional functions Precool / preheat operation Purposes and functions Example of control wiring • The operation of HRV unit is delayed when the air conditioner begins operation. F1 F2 J1 J2...
Page 129 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-2 To connect the remote control to the HRV unit (Part 1) single-group interlocked operation Purposes and functions Example of control wiring When the HRV unit is interlocked to the single-group control system, the remote control for HRV unit will be...
Page 130 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-3 Central control system (DCS302B61) Collective / individual operation (Central remote control) Purposes and functions Example of control wiring It is possible to have collective On / Off or individual On / Central remote control Off without zone control (while setting the 64 zones).
Page 131 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-3 Central control system (DCS302B61) Collective operation (Schedule timer DST301B61) Purposes and functions Example of control wiring • A maximum of 128 units can be controlled the collective Schedule timer operation / stop by weekly schedule.
Page 132 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-3 Central control system (DCS302B61) Collective operation [Adapter PCB for remote control KRP2A Series] Purposes and functions Switch setting of the HRV unit A maximum of 64 groups can be controlled the operation The initial setting is required by the remote control for the of “ON / OFF”...
Page 133 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-3 Central control system (DCS302B61) Multi function central control + Unified On / Off Control Proper control should be selected according to the functions required. System description Central remote control Power Power supply...
Page 134 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-4 Examples of mistakes in wiring and system designing It is necessary to install the remote control for the transmission The centralized transmission line should be connected to line. the indoor unit.
Page 135 • HRV • VAM-FA8VE Control System Applicable patterns 9-3-4 Examples of mistakes in wiring and system designing Setting of Remote Control for HRV unit List of Settings Mode no. Setting position no. (Caution *1.) Setting switch Description of Setting Group...
Page 136: Functions Of Printed Circuit Board
• HRV • VAM-FA8VE Control System Functions of Printed Circuit Board 9-4-1 Layout of switches on Printed Circuit Board Damper Damper Primary Secondary Supply Exhaust air fan air fan Outdoor Thermistor Indoor Thermistor Dumper 2 Dumper 1 KRP50-2 Power supply...
Page 137: Fan Operation Setting
• HRV • VAM-FA8VE Control System Fan operation setting Initial setting by the remote controller for indoor unit Fan operation Fresh-up Fresh-up Ventilation air flow Supply air setting Exhaust air setting Fan speed Fresh-up operation setting Supply side Exhaust side...
Page 138: Operation Mode Change Over
• HRV • VAM-FA8VE Control System Operation mode change over 1. In case of cooling operation 1 zone: Free cooling (cooling by outdoor air) in bypass mode.* 2 zone: Room temperature to be achieved to set Heat Cooling temperature by heat exchange mode.
Page 139: Installation
• HRV • VAM-FA8VE Installation Use a sound-insulating (low-permeability-to-sound) ceiling. Note: Some sound-insulating ceilings are not very effective in 10-1 Reducing operating sound reducing low-frequency element of the operating sound. Place a sound-reducing material under the source of the The air suction and discharge grille may give out operating operating sound.
Page 140 • HRV • VAM-FA8VE Installation 10-1 Reducing operating sound 10-1-4 Effect of remedy for sound Caution 1. Be sure to connect a flexible duct (2 m) to an outlet of the main body in the indoor air supply side. 2. Do not connect a spiral duct and an alminium bellows directly to the outlet of the main body.
Page 141: Centralized Piping
• HRV • VAM-FA8VE Installation 10-2 Centralized piping Fig.2: Install a duct for each HRV unit. Wherever possible, avoid centralized OA and EA pipings Direction of air flow for two or more HRV units, and install ducts for each body of the unit. (Fig. 2) (Indoor side) Because the air flow shown in Fig.1 is generated when centralized...
Page 142: Cautions
In actual installation, the approved smoke back flow prevention dam per is used, Use Daikin's optional smoke back flow prevention 3. Bellows may not be able to use depending on the local regulations.
Page 143 • HRV • VAM-FA8VE Installation 10-3 Cautions 1) Operation in highly humid areas (in cooling mode) To prevent dew formation, use the unit under the condition Note: that the indoor discharge air is 95% RH or less on the If the outdoor discharge air exceeds 95% RH, please preheat psychrometric chart.
Page 144: Cautions In Installation
• HRV • VAM-FA8VE Installation 10-4 Cautions in installation 10-5 Installation Do not use a HRV or an air suction / discharge grille in the following places. 10-5-1 Installation of HRV units • Install the anchor bolt (M10 to 12) in advance.
Page 145: Duct Work
• HRV • VAM-FA8VE Installation 10-6 Duct Work 10-6-2 Going through the external wall 1. Hole diameter 10-6-1 Caution Duct dia. + 50 or 75 • Do not install ducts as shown below. (I.D. depends on the core drill specification) <e.g.>...
Page 146: Electrical Wiring Procedure
• HRV • VAM-FA8VE Installation 10-7 Electrical wiring procedure Before obtaining access to terminal devices, all power supply circuits must be interrupted. Connection of Wiring • Connect the wires in accordance with the diagram of each system. • All wiring must be performed by an authorized electrician.
Page 147 • HRV • VAM-FA8VE Installation 10-7 Electrical wiring procedure PRECAUTIONS 1. Do not connect wires of different gauge to the same power View seen from VRV supply terminal. Looseness in the connection may cause Terminal board for power supply Terminal board for transmission overheating.
Page 148 • HRV • VAM-FA8VE Installation 10-7 Electrical wiring procedure 10-7-1 Opening the switch box VAM1500,2000FA VAM150-1000FA Electric component Printed circuit mounting base board Electrical compartment Grounding terminal mounting base (Electrical compartment cover) Electric component mounting base slide Terminal board Printed circuit board...
Page 149: Initial Setting
• HRV • VAM-FA8VE Installation 10-8 Initial setting 10-8-1 Initial setting by the remote control for indoor unit Purpose Controller Operating procedure for initial setting The following describes the • Interlocked operation • Remote control for indoor unit operating procedure and settings.
Page 150 • HRV • VAM-FA8VE Installation 10-8 Initial setting 10-8-2 Setting procedure of group no. for centralized control The following shows the procedure how to set the group number for the centralized control by the remote control for indoor unit Purpose...
Page 151 • HRV • VAM-FA8VE Installation 10-8 Initial setting 10-8-3 Initial setting for “Central zone control” When HRV unit is connected to the central transmission line (terminal connector no. (F1) and (F2)), it is necessary to make a initial setting of “collective zone interlock”...
Page 153: Part 2: Vkm-Ga(M)V1
• HRV • VKM-GA(M)V1 TABLE OF CONTENTS Part 2: VKM-GA(M)V1 External Appearance ..........153 Model Series .
Page 154 • HRV • VKM-GA(M)V1 TABLE OF CONTENTS Part 2: VKM-GA(M)V1 Outdoor Air Processing of Ceiling Mounted Duct Connection Type ..........247 Stand-alone Operation is Possible as an Independent System .
Page 155: External Appearance
• HRV • VKM-GA(M)V1 1 External Appearance VKM50GAMV1 VKM50GAV1 VKM80GAMV1 VKM100GAMV1 VKM80GAV1 VKM100GAV1 2 Model Series Type 1000 DX-Coil and Humidifier VKM50GAMV1 VKM80GAMV1 VKM100GAMV1 DX-Coil VKM50GAV1 VKM80GAV1 VKM100GAV1 These units are applied only for CE regulation. • HRV • Heat Reclaim Ventilation...
Page 156: Nomenclature
• HRV • VKM-GA(M)V1 3 Nomenclature V K M 50 GA M V1 Ventilation Outdoor Air Treatment Type Mounted Type Nominal Air Flow Rate 50 : 500m /h, 80 : 750m /h, 100 : 950m Major Design Category Moisture (M : With Humidifier Elements, nothing : without Humidifier Elements) Power Supply V1 : 1 Phase : 220-240V, 50Hz 4 Structures...
Page 157: Features
• HRV • VKM-GA(M)V1 5 Features General • Interlocked operation with VRV (Controls of interlocked operation for energy saving : The remote controller for air conditioner can be used, so special remote controller for HRV is unnecessary.) • Mounted for direct expansion coil unit for outdoor air treatment •...
Page 158: Energy Saving
• HRV • VKM-GA(M)V1 5.2.3 Indoor Unit Connectable to up to 130% of the Capacity 5.2.4 Slim Design The slim design of only 387 mm in height enables installation inside ceilings with less than 400 mm of clearance. Energy Saving 5.3.1 Automatic Heat Purge Function at Night Not operation...
Page 159 • HRV • VKM-GA(M)V1 Nighttime Free Cooling Operation <Flow Chart> Nighttime Free Cooling Nighttime Free Cooling Operating Condition Precedent Condition Air-conditioner Operation <STOP> Air-conditioner Operation <RUN> Nighttime free cooling Operation <ON> Temp. monitor operation time Standard mode > Lapsed time setup <Lapsed time>...
Page 160: Unique Control System
• HRV • VKM-GA(M)V1 5.3.3 Efficient Outdoor Air Introduction with Heat Exchanger and Cooling / Heating Operation Indoor unit with outdoor air treatment Using outdoor air, the temperature can be brought near room temperature with minimal cooling capacity through the Outdoor air temperature use of outdoor air.
Page 161: Other Features
Features • Fan speed can be set at the initial setting. Connectable Indoor unit VRV (all indoor unit) Other types Daikin’s HRV FAN mode No falling of dust Dust (HC0006) (HC0005) Dust does not fall off from the air filter because the...
Page 162 • HRV • VKM-GA(M)V1 Installation Examples Direct duct connection system Independent duct system (HC0007) (HC0008) 5.7.2 Mechanism of Energy Saving HRV unit recovers the thermal energy during cooling / heating operation of air conditioner. HRV reduces the cooling / heating load drastically and By heat recovery operation enhances the heating / cooling efficiency.
Page 163 • HRV • VKM-GA(M)V1 5.7.3 Fresh-up Operation Both the excessive supply mode and the excessive exhaust mode are selectable. This function creates a more comfortable air environment. Supply Fresh-up Exhaust Fresh-up (Excessive outdoor air supply) (Excessive exhaust air supply) Supply air volume can be set at a higher level Exhaust air volume can be set at a higher level Detail than the exhaust air by the remote controller.
Page 164 Height (mm) VKM50GAMV1 VKM50GAV1 VKM80GAMV1 VKM80GAV1 VKM100GAMV1 VKM100GAV1 Parallel air flow system (Daikin) Cross air flow system (Others) This system prevents misconnection and simplifies the installation work (HC0235) (HC0234) 5.7.6 The Operation is Available When the Outdoor Air Temperature is Down to -15°C (Operation when the outdoor air temperature becomes lower than -10°C)
Page 165: Selection Procedures (In Japan)
• HRV • VKM-GA(M)V1 6 Selection Procedures (in Japan) Various methods are used to calculate the required ventilating air flow rate according to CO generated by inhabitants in a room, waste gas generated by use of fire, and other conditions of a room. Here are 2 patterns of calculating methods.
Page 166 • HRV • VKM-GA(M)V1 <Table 2> Ventilation Ventilation Groups Type of room Groups Type of room required required Living room Audience room Bathroom Corridor Playhouses Common Drawing room and movie Smoking room household theaters Toilet Toilet Kitchen Projector room Restaurant Office room Sushi restaurant General work room...
Page 167: Product Specification
• HRV • VKM-GAMV1 - G M H e a H R V V K M Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 1 Specifications TECHNICAL SPECIFICATIONS VKM80GAMV1 VKM100GAMV1 VKM50GAMV1 Fresh air Cooling 7.46 9.12 4.71 conditioning load Heating 8.79 10.69...
Page 168 • HRV • VKM-GAMV1 TECHNICAL SPECIFICATIONS VKM80GAMV1 VKM100GAMV1 VKM50GAMV1 Piping connection Liquid Type flare connection Diameter Type flare connection Diameter 12.7 12.7 12.7 Water supply Drain PT3/4 external thread Refrigerant control electronic expansion valve Insulation material Self-extinguishable urethane foam Heat exchange system Air to air cross flow total heat (sensible + latent heat) exchange Heat exchange element Specially processed non-flammable paper...
Page 169 • HRV • VKM-GAMV1 ELECTRICAL SPECIFICATIONS VKM80GAMV1 VKM100GAMV1 VKM50GAMV1 Power Supply Name Phase Frequency Voltage 220-240 Nominal running Heat exchange Ultra-high 3.00 3.00 3.00 current (RLA) mode High 2.60 2.50 2.50 2.10 2.10 2.10 Bypass mode Ultra-high 3.00 3.00 3.00 High 2.60 2.50...
Page 170 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 HUMIDIFIER VKM50GAMV1 VKM80GAMV1 VKM100GAMV1 VKM50GAMV1 VKM80GAMV1 VKM100GAMV1 Humidifier type Natural evaporating type humidifier Porosity plate 120 pcs. Wetted element Porosity plate 60 pcs. Porosity plate 90 pcs. (60×2 pcs.) φ6.4 C1220T (Flare Connection) Water inlet port Water outlet port PT3/4...
Page 171: Vkm-Gav1
• HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 2 Options VKM-GA(M)V1 Air suction/discharge grille ( option) Flexible duct (option) High efficient filter (option) Round hood Branch duct (field supply) (field supply) Silencer (option) Duct (field supply) Thermal insulation material ( f ield supply) VKM-GAV1...
Page 172 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 3 Capacity tables 7 - 1 - 3 - 1 Cooling capacity tables VKM-GA(M) TC: Total capacity : kW; SHC : Sensible heat capacity : kW Coil Inlet air temp.°CDB Capacity Outdoor...
Page 173 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 3 Capacity tables 7 - 1 - 3 - 2 Heating capacity tables VKM-GA(M) Capacity Outdoor Coil Inlet air temp.°CDB Class DX-Coil °CDB °CWB 16.0kW 18.0kW 20.0kW 21.0kW 22.0kW...
Page 174 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 3 Capacity tables 7 - 1 - 3 - 3 Capacity correction factor Correction ratio 4D023764 • HRV • Heat Reclaim Ventilation...
Page 175 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 4 Dimensional drawing & centre of gravity 7 - 1 - 4 - 1 Dimensional drawing VKM50GAMV1 Supply air fan Damper plate Direct expansion coil Feed water tank Hanger bracket NOTES 4-14x40 oval hole...
Page 176 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 4 Dimensional drawing & centre of gravity 7 - 1 - 4 - 1 Dimensional drawing VKM100GAMV1 Supply air fan Damper plate Direct expansion coil Feed water tank Hanger bracket NOTES 4-14x40 oval hole...
Page 177 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 5 Wiring diagram VKM50,80,100GAMV1 Power supply 220-240V Note 5 Note 7 50 Hz Note 5 Adapter PC board for wiring External output (optional accessories) terminals Note 2 Contact capacity Note 6...
Page 178 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 6 Sound data 7 - 1 - 6 - 1 Sound pressure spectrum VKM50GAMV1 VKM50GAMV1 Approximate threshold hearing for continuous Approximate noise threshold hearing for continuous Octave band center frequency (Hz) noise 4D051291...
Page 179 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 6 Sound data 7 - 1 - 6 - 1 Sound pressure spectrum VKM80GAMV1 VKM80GAMV1 Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 180 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 6 Sound data 7 - 1 - 6 - 1 Sound pressure spectrum VKM100GAMV1 VKM100GAMV1 Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 181 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 7 Reducing Operating Sound The air suction and discharge grille may give out operating sound higher by 8 to 11 phons than of the HRV units body. When installing this unit in a quiet place, take measures to reduce operating sound.
Page 182 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 7 Reducing Operating Sound 7 - 1 - 7 - 3 Reducing Operating Sound Heard from the Air Discharge Outlet (Suction Inlet) 1. Use the following recommended optional accessories to reduce 3.
Page 183 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 7 Reducing Operating Sound 7 - 1 - 7 - 5 General Comparison of the Effect ((1) → (6) in more Effective Order) Mounting a silencer + flexible duct 2 m long Mounting a flexible duct Mounting a flexible duct 6 m long...
Page 184 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 8 Fan characteristics VKM50GAMV1 VKM80GAMV1 Exchange efficiency Exchange efficiency 50Hz, 220V-240V 50Hz, 220V-240V Operating air flow rate range Operating air flow rate range ø200 Pipe lenght Ultra High Ultra High ø250...
Page 185 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 9 Installation 7 - 1 - 9 - 1 Installation method VKM50GAMV1 NOTES Leave space for servicing the unit and include inspection hatch. (Always open a hole on the side of the control box so that the air filters, heat exchange elements, fans, and humidifier elements can easily be inspected and serviced.) Install the two outdoor ducts with down slope (slope of 1/30 or more) to prevent...
Page 186 • HRV • VKM-GAMV1 Product Specification 7 - 1 VKM-GAMV1 7 - 1 - 9 Installation 7 - 1 - 9 - 1 Installation method VKM100GAMV1 NOTES Leave space for servicing the unit and include inspection hatch. (Always open a hole on the side of the control box so that the air filters, heat exchange elements, fans, and humidifier elements can easily be inspected and serviced.) Install the two outdoor ducts with down slope (slope of 1/30 or more) to prevent...
Page 187 • HRV • VKM-GAV1 H e a H R V V K M Product Specification 7 - 2 VKM-GAV1 7 - 2 - 1 Specifications TECHNICAL SPECIFICATIONS VKM100GAV1 VKM80GAV1 VKM50GAV1 Fresh air Cooling 9.12 7.46 4.71 conditioning load Heating 10.69 8.79 5.58 Power input...
Page 188 • HRV • VKM-GAV1 TECHNICAL SPECIFICATIONS VKM100GAV1 VKM80GAV1 VKM50GAV1 Connection duct diameter Operation mode Heat exchange mode, bypass mode, fresh-up mode Standard Item Installation and operation manual Accessories Duct connection flange M4 tapping screw to connect duct refrigerant piping insulation cover clamp Notes Cooling and heating capacities...
Page 189 • HRV • VKM-GAV1 ELECTRICAL SPECIFICATIONS VKM100GAV1 VKM80GAV1 VKM50GAV1 Power Supply Name Phase Frequency Voltage 220-240 Nominal running Heat exchange Ultra-high 3.00 3.00 3.00 current (RLA) mode High 2.50 2.60 2.50 2.10 2.10 2.10 Bypass mode Ultra-high 3.00 3.00 3.00 High 2.50 2.60...
Page 190 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 2 Options VKM-GA(M)V1 Air suction/discharge grille ( option) Flexible duct (option) High efficient filter (option) Round hood Branch duct (field supply) (field supply) Silencer (option) Duct (field supply) Thermal insulation material ( f ield supply) VKM-GAV1...
Page 191 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 3 Capacity tables 7 - 2 - 3 - 1 Cooling capacity tables VKM-GA(M) TC: Total capacity : kW; SHC : Sensible heat capacity : kW Coil Inlet air temp.°CDB Capacity Outdoor...
Page 192 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 3 Capacity tables 7 - 2 - 3 - 2 Heating capacity tables VKM-GA(M) Capacity Outdoor Coil Inlet air temp.°CDB DX-Coil Class °CDB °CWB 16.0kW 18.0kW 20.0kW 21.0kW 22.0kW...
Page 193 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 3 Capacity tables 7 - 2 - 3 - 3 Capacity correction factor Correction ratio 4D023764 • HRV • Heat Reclaim Ventilation...
Page 194 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 4 Dimensional drawing & centre of gravity 7 - 2 - 4 - 1 Dimensional drawing VKM50GAV1 Supply air fan Damper plate Direct expansion coil Hanger bracket NOTES 4-14x40 oval hole 1688...
Page 195 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 4 Dimensional drawing & centre of gravity 7 - 2 - 4 - 1 Dimensional drawing VKM100GAV1 Supply air fan Damper plate Direct expansion coil Hanger bracket NOTES 4-14x40 oval hole 1688...
Page 196 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 5 Wiring diagram VKM50,80,100GAV1 Power supply 220-240V 50 Hz Adapter PC board for wiring External output (optional accessories) Note 2 terminals Contact capacity AC220-240V 0.01~1.6A Note 3 Input from Note 4 outside...
Page 197 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 6 Sound data 7 - 2 - 6 - 1 Sound pressure spectrum VKM50GAV1 VKM50GAV1 Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 198 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 6 Sound data 7 - 2 - 6 - 1 Sound pressure spectrum VKM80GAV1 VKM80GAV1 Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 199 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 6 Sound data 7 - 2 - 6 - 1 Sound pressure spectrum VKM100GAV1 VKM100GAV1 Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
Page 200 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 7 Reducing Operating Sound The air suction and discharge grille may give out operating sound higher by 8 to 11 phons than of the HRV units body. When installing this unit in a quiet place, take measures to reduce operating sound.
Page 201 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 7 - 2 Reducing Operating Sound Heard from the Air Discharge Outlet (Suction Inlet) 1. Use the following recommended optional accessories to reduce operating sound heard from attic-installed duct type models. 3.
Page 202 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 7 Reducing Operating Sound 7 - 2 - 7 - 4 General Comparison of the Effect ((1) → (6) in more Effective Order) Mounting a flexible duct Mounting a flexible duct Mounting a silencer + flexible duct 2 m long 6 m long...
Page 203 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 8 Fan characteristics VKM50GAV1 VKM80GAV1 Exchange efficiency Exchange efficiency 50Hz, 220V-240V 50Hz, 220V-240V Operating air flow rate range Operating air flow rate range ø200 Pipe length Ultra High Ultra High ø250...
Page 204 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 9 Installation 7 - 2 - 9 - 1 Installation method VKM50GAV1 Air discharge grille NOTES (Locally procured) Air suction grille Leave space for servicing the unit and include inspection hatch. (Locally procured) Heat insulator (Always open a hole on the side of the control box so that the air...
Page 205 • HRV • VKM-GAV1 Product Specification 7 - 2 VKM-GAV1 7 - 2 - 9 Installation 7 - 2 - 9 - 1 Installation method VKM100GAV1 Air suction grille NOTES Air discharge grille Heat insulator (Locally procured) (Locally procured) (Locally procured) 1688 Leave space for servicing the unit and include inspection hatch.
Page 206: Operation
• HRV • VKM-GA(M)V1 8 Operation HRV; Heat Reclaim Ventilation • Carefully read this operation manual before using the total heat exchanger. It will tell you how to use the unit properly and help you if any trouble occurs. This manual explains about the indoor unit only. Use it along with the operation manual for the outdoor unit.
Page 207 • HRV • VKM-GA(M)V1 • Combined operation system with VRV systems Indoor unit HRV-With DX Coil- Remote controller for indoor unit Outdoor unit • Independent system HRV-With DX Coil- Outdoor unit Remote controller for indoor unit Remote controller for VRV BRC1A62 Figure 2 Figure 3 Remote controller for VKM BRC1D527 (EU only)
Page 208: Safety Cautions
• HRV • VKM-GA(M)V1 UNIT No. GROUP 1,2,3 1,2,3 Remote controller for VKM BRC1D527 (EU only) Remote controller for VRV BRC1A62 Figure 6 Figure 6 UNIT No. GROUP 1,2,4 Remote controller for VRV BRC1A62 Remote controller for VKM BRC1D527 (EU only) Figure 7 Figure 7 (1) Air filter...
Page 209 • HRV • VKM-GA(M)V1 CAUTION..Improper handling can lead to injury or damage. It could also have serious consequences under certain conditions. Note • These instructions will ensure proper use of the equipment. Be sure to follow these important safety cautions. Keep these warning sheets handy so that you can refer to them if needed.
Page 210 • HRV • VKM-GA(M)V1 WARNING (For installation) • Do not attempt to install the unit yourself. Ask your dealer for installation of the unit. Incomplete installation performed by yourself may result in a water leakage, electric shock, and fire. • Installation should be done following the installation manual.
Page 211: What To Do Before Operation
This operation manual is for the following systems with standard control. Before initiating operation, contact your Daikin dealer for the operation that corresponds to your system type and mark. If your installation has a customized control system, ask your dealer for the operation that corresponds to your system.
Page 212 • HRV • VKM-GA(M)V1 8.2.1 Name of Parts (Refer to Figure 1) 8.2.2 Remote Controller and Changeover Switch : Name and Function of Each Switch and Display (Refer to Figure 3 and 4) Only the items marked with an asterisk (∗ mark) are explanation relating to the functions and display of the unit.
Page 213 • HRV • VKM-GA(M)V1 18. Temperature setting button Use this button for setting the desired temperature of air conditioner combined with this unit. This button can’t use for this unit. This unit can’t change temperature setting. 19. ∗Filter sign reset button Refer to “8.4.1 How to clean the Air Filter”.
Page 214 • HRV • VKM-GA(M)V1 41. OPERATION CHANGE/ BUTTON “ ” This button is a multi-purpose button. Depending on the previous manipulations of the user, it can have following functions: 1. select the operation mode of the installation (FAN, DRY, AUTOMATIC, COOLING, HEATING) 2.
Page 215 • HRV • VKM-GA(M)V1 The HRV unit cannot be operated independently when the air conditioner is connected to the HRV unit via a duct. When using the HRV unit, set the air conditioner to “fan” mode on weak fan strength. Operation mode display “Ventilation”...
Page 216 • HRV • VKM-GA(M)V1 Example 2 : In case of the remote controller “BRC1A62” Display changes as below. When air conditioner and HRV When air conditioner and HRV unit are not connected via duct unit are connected via duct <Operation mode> <Operation mode>...
Page 217: Operation Procedure
• HRV • VKM-GA(M)V1 Operation Procedure 8.3.1 Cooling, Heating and Fan Only Operation (Refer to Figure 5) [PREPARATIONS] • To protect the unit, turn on the main power switch 6 hours before operation. Do not turn off the power during the heating or cooling season. This is to ensure smooth start-up. Press the operation mode selector button several times and select the operation mode of your choice;...
Page 218 ” and “ ” when it is combined with an air conditioner (Not producted by Daikin) and based on only the information from the HRV unit (indoor and outdoor temperatures) when the HRV unit is operating alone. Total heat exchange mode : Outdoor air passes through the heat exchange element and heat exchanged air is sent into the room.
Page 219 • HRV • VKM-GA(M)V1 HOW TO DESIGNATE THE MASTER REMOTE CONTROLLER Press the operation mode selector button of the current master remote controller for 4 seconds. The display showing“ ” (changeover under controll) of all slave remote controllers connected to the same outdoor unit or BS unit flashes on.
Page 220 • HRV • VKM-GA(M)V1 Press the timer on/off button. The timer setting procedure ends. The display “ ” or “ ” changes from flashing light to constant light. • After the timer is programmed, the display shows the remaining time. For cancelling the timer operation, push the timer on/off button “...
Page 221 • HRV • VKM-GA(M)V1 Press the “ ” button to display the next programmed action. If a second action is programmed for Monday, “ ” will still be blinking and “ ” will appear. Assuming that 5 actions were programmed for Monday, a total of 5 presses will be required to display all programmed actions.
Page 222: Maintenance (For A Qualified Service Person Only)
• HRV • VKM-GA(M)V1 Note • When the fan motor fails, the remote controller does not display any error code. Usage under that status will lead to insufficient ventilation. The air supply and exhaust fans should be checked once every one or two months. You can make a simple check such as below way.
Page 223 • HRV • VKM-GA(M)V1 (5) Install the maintenance cover. (Refer to 8.4.1, (1)). For remote controllers which display the filter sign, turn on the power after maintenance, and press the filter sign reset button. ∗ Consult your dealer if you want to change the time setting for when the filter sign goes on. CAUTION •...
Page 224: Trouble Shooting
It is only displayed temporarily. 8.5.2 If One of the Following Malfunctions Occurs, take the Measures Shown below and Contact Your Daikin Dealer. The system must be repaired by a qualified service person. DO NOT CHECK AND REPAIR OPENING INSIDE THE UNIT BY YOURSELF.
Page 225 OPERATION lamp and the OPERATION lamp flash and the “MALFUNCTION CODE” appears. Measure: Notify and inform the model name and what the malfunction code indicates to your Daikin dealer. INDOOR UNIT No. in INSPECTION display which a malfunction occurs MALFUNCTION CODE •...
Page 226: After-Sales Service And Warranty
• HRV • VKM-GA(M)V1 8.5.3 If the System does Not Properly Operate Except for the Above Mentioned Case, and None of the Above Mentioned Malfunctions is Evident, Contact your Dealer, and Request for Investigation the System According to the Following Procedures by a Qualified Service Person. The following malfunctions must be checked by a qualified service person.
Page 227 • HRV • VKM-GA(M)V1 When asking your dealer to repair, inform related staff of the details as follows: • Shipping date and installation date: • Malfunction: Inform the staff of the defective details. (Malfunction code being displayed on the remote controller.) •...
Page 228 • HRV • VKM-GA(M)V1 Recommended replacement cycle of wear-out parts [The cycle is not the same as the warranty period.] • Table 2 “Replacement Cycle” Lists Name of Main Part Inspection Cycle Replacement Cycle Air filter 3 years 1 year High efficiency filter (Optional accessory) 1 year Heat exchanger element...
Page 229: Installation
When installing the unit, have ready the round shape hood, the air discharge grille and the air suction grille, and other parts needed for the installation. Consult your Daikin dealer when selecting optional accessories. • HRV • Heat Reclaim Ventilation...
Page 230: Selecting Installation Site
• HRV • VKM-GA(M)V1 FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND CHECK AFTER INSTALLATION IS FINISHED. a. Items to be checked after completion of work Items to be checked If not properly done, what is likely to occur Check Are the indoor and outdoor unit fixed firmly? The units may drop, vibrate or make noise.
Page 231: Preparations Before Installation
• HRV • VKM-GA(M)V1 • Where sufficient clearance for maintenance and service can be ensured. (Refer to Fig. 1) Unit (mm) 600 or more Electric parts box Maintenance space minimum hight ∗H 20 or more Fig. 1 • Select the ∗H dimension such that a downward slope of at least 1/100 is ensured as indicated in “9.5 Drain Piping and Water Supply Work”.
Page 232: The Method Of Installation
• HRV • VKM-GA(M)V1 4. Install the suspension bolts. (Use M10 to M12 suspension bolts.) Ceiling slab Use a hole-in-anchor, sunken insert, Anchor bolt sunken anchor for existing ceilings, or Antivibration lifting other part to be procured in the field to lug or turn buckle reinforce the ceiling to bearing the Suspension bolt...
Page 233: Drain Piping And Water Supply Work
• HRV • VKM-GA(M)V1 (6) Attach the accessory duct connecting flanges using the included screws to the outlet and intake holes (a total of four). When attaching, make sure the alignment markings on the unit match up with the triangle on the each duct connecting flange.
Page 234 • HRV • VKM-GA(M)V1 (2) After piping work is finished, check drainage flows smoothly. • Test the drainage by pouring around 1000cc of water into the drain pan through the inspection hole by removing the maintenance cover (10 screws) or through the outlet duct joint of supply air to room (SA).
Page 235: Refrigerant Piping Work
• HRV • VKM-GA(M)V1 [PRECAUTIONS] • Use pure water (city water, tap water or equivalent) that satisfies the standard regulated by the law of each country for water supply to the humidifier when performing anti-sweat work. • Dirty water may cause valves to clog, dirt to accumulate in water tanks, and resulting in poor humidifier performance.
Page 236 • HRV • VKM-GA(M)V1 • When connecting the flare nut, coat the flare section (both inside and outside) with ester oil or ether oil, rotate three or four times first, then screw in. (Refer to Fig. 12) Torque wrench Ester oil or ether oil Spanner Flare nut Piping union...
Page 237: Duct Connection
Using flexible or silent ducts can be effective in reducing the air discharge sound of the supply air to room (SA). Select materials keeping in mind the fan strength and operating sound of the unit. Consult your Daikin dealer for selection. •...
Page 238: Electric Wiring Work
• HRV • VKM-GA(M)V1 • When using a deep hood, make sure the duct from the deep hood (outer wall) to the unit is at least 1m long. Outdoor duct Slope: Aluminum tape Over 1/30 Insulation material (Locally procured) (Locally procured) Make sure there is no slack in the duct.
Page 239: Wiring Example And How To Set The Remote Controller
• HRV • VKM-GA(M)V1 Note • If the wiring is in a place where people it can be easily touched by people, install a leak interrupter to prevent electric shock. • When using a ground-fault circuit interrupter, make sure to select one useful also to protection against overcurrent and short-circuit.
Page 240 • HRV • VKM-GA(M)V1 9.9.2 Connecting Power Supply Wiring and Ground Wiring • Pass the power supply wiring and the ground wiring through the wiring through-hole into the electrical parts box and secure with the included clamping material after connecting the wires to terminal blocks. (Refer to Fig.
Page 241 • HRV • VKM-GA(M)V1 [5] Tightening torque for the terminal screws. • Use the correct screwdriver for tightening the terminal screws. If the blade of screwdriver is too small, the head of the screw might be damaged, and the screw will not be properly tightened. •...
Page 242 • HRV • VKM-GA(M)V1 9.9.5 Wiring Example • This unit can be used as part of the combined operation system used together with indoor units (VRVIII system air conditioners), or as an independent system for processing outside air. • When connecting with a cooling free building multi type and bringing the RA (exhaust gas intake) of this unit directly in from the ceiling, connect to a BS unit identical to the building multi indoor unit (master unit), and use group-linked operation.
Page 243 • HRV • VKM-GA(M)V1 〈When including a BS unit〉 Power supply Power supply 220-240V 220-240V Outdoor unit 50 Hz 50 Hz Electric parts box IN/D OUT/D Switch Switch F1 F2 F1 F2 Transmission wiring (No polarity) Fuse Fuse BS unit Remote Electric parts box controller...
Page 244 • HRV • VKM-GA(M)V1 〈Wiring Method〉 (See “9.8 Electric Wiring Work”.) 1. Remove the electric parts box lid. 2. Add remote controller 2 (slave) to the terminal block for remote controller (P ) in the electric parts box. (There is no polarity.) REMOTE TRANSMISSION FORCED...
Page 245: Field Setting And Test Run
• HRV • VKM-GA(M)V1 9.9.9 Fresh-up Operation by External Input (HRV Unit) PURPOSES AND FUNCTIONS When the operation is interlocked with the local ventilating fan(such as the one for toilet or kitchen), the HRV unit performs the over-supply operation to prevent inflow of the odor from outside. The flow rate of supply air becomes higher than that of exhaust air.
Page 246 • HRV • VKM-GA(M)V1 (7) Press the INSPECTION/TRIAL button to return to normal mode. UNIT No. (4) (5) (4) (5) GROUP (7) (1) (1) (7) (6) (4) (5) 〈Example〉 When adjusting the ventilation air flow to low setting in the group setting mode, enter the Mode No., “19”...
Page 247 • HRV • VKM-GA(M)V1 6. See below for details on the settings for cold areas. – : operate at the set fan strength Air conditioner fan Heating thermo off Operation – – Defrost Stop – Stop Stop Stop Oil return Stop –...
Page 248 • HRV • VKM-GA(M)V1 9.10.3 Next, run the Humidifier. 〈VKM-GAMV1 series only〉 (1) Check that the water supply piping is connected securely. (2) Open the water supply shut-off valve. (No water will be supplied at this time.) (3) Run the HRV unit in heating mode. (See the operating manual included with the indoor unit for details on how to run the unit in heating mode.) The water supply will start and the humidifier will begin operation.
Page 249: Outdoor Air Processing Of Ceiling Mounted Duct
• HRV • VKM-GA(M)V1 10 Outdoor Air Processing of Ceiling Mounted Duct Connection Type The structure of VKM-GAMV1 model is different from other ventilation models. Points you need to note are summarized below, which please use for your reference when selecting the model. 10.1 Stand-alone Operation is Possible as an Independent System Because no function to control the room temperature is equipped, only the operation mode (cooling, heating, automatic, ventilation) is displayed on the remote controller.
Page 250: Central Control System
• HRV • VKM-GA(M)V1 [Points to be noted for VKM-GA(M)] There are following restrictions with VKM-GA(M) model due to its own controlling structure. 1. Stand alone system: No address setting is required because of its automatic addressing function (corresponding multiple type for building P-board : Master). Because it is under a group control, it is always required to connect to a remote controller.
Page 251: Restrictions To Control System
• HRV • VKM-GA(M)V1 • Structure without a remote controller cannot be accepted because the remote controller group is controlled within a VKM-GA(M) model. (intelligent Touch Controller, central control controller) Group interlock zone setting : None Without a remote controller Zone interlock setting : None * Alteration of set temperature and independent ventilation operation cannot be performed from a central device.
Page 252: About The Basic Control Of Vkm
• HRV • VKM-GA(M)V1 10.4.3 Caution when Connecting the Indoor Unit Directly to the Duct Follow the indications described below a) When connecting the indoor unit directly to the duct, always use the same system on the indoor unit as with the outdoor unit, perform group-linked operation, and make the direct duct connection settings from the remote controller.
Page 253: Appendix
• HRV • VKM-GA(M)V1 11 Appendix 11.1 Purpose of Ventilation Living environment, and working environment as well, can be polluted for various reasons, which in turn will lead to hygienic problems and/or lower productivity. To avoid this, the polluted air must be replaced with fresh air.
Page 254 • HRV • VKM-GA(M)V1 Tobacco Only one cigarette can soon pollute the air in the enclosed room. And both the smoker and other non- smokers staying here are affected. Especially the “secondhand” smoke from the tip of cigarette contains 2~3 times larger amount of harmful substances (nicotine and tar) than the “main smoke” exhaled by the smoker, so that the non-smokers around the smoker can be affected by tobacco smoke.
Page 255 • HRV • VKM-GA(M)V1 Table 6 Effect of Carbon Monoxide (CO) Concentration (ppm) Effect of change in concentration 0.01~0.2 Standard atmosphere Long-term based allowable value Building Standard Act and Building Control Act use this value as the 24-hour average environmental standard. About 5 ppm in annual average Short-term based allowable value: 8-hour for urban roads;...
Page 256 • HRV • VKM-GA(M)V1 Table 7 Effect of Carbon Dioxide (CO Concentration (%) Effect of change in concentration 0.03(0.04) Standard atmosphere 0.04~0.06 Urban atmosphere Allowable concentration for many persons 0.07 staying in a room These concentration limits are defined as a pollution indicator Allowable concentration for general cases: within a hypothesis that the 0.10...
Page 257: Kinds Of Ventilation
• HRV • VKM-GA(M)V1 • Yawning is a sign of insufficient oxygen You may think that persons who frequently yawn have no concentration. However, this is not the case depending on the situation. Yawning is a physiological phenomenon that can occur when the brain is suffering from the shortage of oxygen.
Page 258 • HRV • VKM-GA(M)V1 <Mechanical ventilation> Whole ventilation This is to replace all air in the room with fresh air. This Exhaust system is effective for rooms in which there is a source of smoke, steam or odor. Dirty air Supply Local ventilation This is to replace air in a limited area where the air is polluted.
Page 259 • HRV • VKM-GA(M)V1 11.2.2 Air Flow (Quantity), and Dynamic and Static Pressure Ventilation fan performance parameters include air flow (quantity) and static pressure. These two parameters relate closely to each other. Ventilation cannot be designed without these two parameters. The first step of “designing a ventilation system”...
Page 260 • HRV • VKM-GA(M)V1 11.2.3 Mechanical Fan Types and their Characteristics Axial fan and centrifugal fan Ventilation fan are roughly classified into two types: axial fans and centrifugal fans. These two types of ventilation fans are selected depending on the operating conditions and/or application. Axial fan is normally a propeller fan available for applications for larger flow but at smaller pressure rating ranging between 0 and 30 Pa.
Page 261 • HRV • VKM-GA(M)V1 11.2.4 Operating Sound As well as the required airflow and static pressure, the operating sound (noise level) is an important factor for determining the type of ventilating fans. The noise level allowable limit may have been defined depending on the use of the room to be ventilated.
Page 262 • HRV • VKM-GA(M)V1 11.2.5 Required Air Flow When calculating the required air flow (ventilating capacity), various factors, including CO production by the persons staying therein and production of combustion gases, should be considered. Calculations should consider all of the requirements that the room should meet. Calculate air flow based on the occupied area per person 20 ×...
Page 263 • HRV • VKM-GA(M)V1 Calculate air flow based on the required air flow per floor area Required air flow (m = Required air flow per floor area (m · h) × Floor area (m Required air flow per floor area (1m Room Air flow rate Office...
Page 264: Calculation Of Duct Pressure Loss
• HRV • VKM-GA(M)V1 Required air flow based on tobacco smoking and odor 6-class odor level presentation (this classification is linked with an approximate, intuitive estimation of gas concentration) Odor intensity Description Odorless Manages to detect the presence of odor (threshold concentration) Manages to detect what is producing the odor (threshold concentration) Easily detects the odor Strong odor...
Page 265 • HRV • VKM-GA(M)V1 11.3.1 Procedure for Calculating Pressure Drops and Finally Determining the Type of Ventilators Calculation of required air flow Ducting design (duct diameter, type, routing, length and bends) Calculate the Using the equivalent pressure losses of straight piping length the straight sections conversion table, using "the friction...
Page 266 • HRV • VKM-GA(M)V1 2. Using the duct's friction resistance diagram Friction resistance diagram for round duct (galvanized steel pipe) 0.04 1000000 800000 600000 400000 200000 100000 80000 60000 40000 20000 10000 8000 6000 4000 2000 1000 0.04 Friction loss factor γ [Pa/m] Friction Resistance Diagram for Duct <How to use the diagram>...
Page 267 • HRV • VKM-GA(M)V1 Conversion from rectangular to round duct Long side Short side <How to use the chart> Example) A rectangular duct of 40×200 is equivalent to a round duct of 90 in diameter. I) Find the intersection of the short side 40 and long side 200 : Point A. II) Draw the line B passing through Point A until it intersects with the slant line C : Point D.
Page 268 • HRV • VKM-GA(M)V1 The right column of Table A shows le : equivalent straight pipe length of partial resistance...[m] ζ the duct diameter equivalent to this d : straight pipe diameter..........[m] le = pressure loss of the local feature. λ...
Page 269: Notes For Ducted Systems
• HRV • VKM-GA(M)V1 • To convert a local resistance to the Equivalent straight pipe length Piping part (pipe diameter 100) equivalent straight pipe length, use the Table 0.5m A shown in the previous page. • For this example, the equivalent length can be calculated as follows.
Page 270: How To Use Psychrometric Chart
• HRV • VKM-GA(M)V1 Bend located too close to the fan Duct Bending the duct near the shutter frame may not permit the shutter to open completely. To avoid this, there should be a distance of minimum 150 mm between the bend and shutter.
Page 271 • HRV • VKM-GA(M)V1 11.5.1 Unit conversion tables General conversion tables Pressure Velocity Area Weight • HRV • Heat Reclaim Ventilation...
Page 272 • HRV • VKM-GA(M)V1 Length Flow rate • HRV • Heat Reclaim Ventilation...
Page 273 • HRV • VKM-GA(M)V1 SI unit used for refrigeration / air conditioning and conversion table Units mainly used in Units mainly JIS unit integral multiple of 10 of used in integral Amount SI unit Remarks unit used in combination Other units multiple of 10 of with SI unit or of unit SI unit...
Page 274 • HRV • VKM-GA(M)V1 Pressure conversion table kgf/cm MPaG p.s.i.G kgf/cm MPaG p.s.i.G p.s.i.G MPaG kgf/cm p.s.i.G MpaG kgf/cm 0.00 12.0 1.18 170.6 0.00 2.41 24.6 0.02 12.2 1.20 173.5 0.03 2.45 25.0 0.04 12.4 1.22 176.3 0.07 2.48 25.3 0.06 12.6 1.23...
Page 275 • HRV • VKM-GA(M)V1 Temperature conversion table • HRV • Heat Reclaim Ventilation...
Page 276 • HRV • VKM-GA(M)V1 11.5.2 Refrigerant Fluorocarbon and global environment Influence of refrigerant given on global environment 1. Ozone layer destruction Space beyond the earth's atmosphere Ozone layer destruction due to chlorine contained in Upper atmosphere fluorocarbon Stratosphere (ozone layer) Intrusion of harmful ultraviolet rays Troposphere...
Page 277 • HRV • VKM-GA(M)V1 2. Global warming (Principle) Due to the results of human activities such as a large quantity of consumption of petrochemical fuels (e.g. petroleum, coal, and natural gas) and forest destruction, carbon dioxide, chlorofluorocarbon, methane, and others in the atmosphere have been increasing beyond the limit that natural force can remove them.
Page 278 • HRV • VKM-GA(M)V1 Refrigerant R-410A saturation curve Temperature (˚C) • HRV • Heat Reclaim Ventilation...
Page 279 • HRV • VKM-GA(M)V1 R-410A Saturation pressure (gauge pressure) chart • HRV • Heat Reclaim Ventilation...
Page 280 • HRV • VKM-GA(M)V1 Thermodynamic characteristics of R-410A DAIREP ver2.0 Steam pressure Density Specific entropy Specific heat at constant Specific enthalpy Temperature pressure (kj/kgK) (kPa) (kg/m (kj/kg) (kj/kgK) (°C) Liquid Vapor Liquid Vapor Liquid Vapor Liquid Vapor Liquid Vapor (Z0168) •...
Page 281 • HRV • VKM-GA(M)V1 (Z0169) • HRV • Heat Reclaim Ventilation...
Page 282 • HRV • VKM-GA(M)V1 11.5.3 Psychrometric Chart • HRV • Heat Reclaim Ventilation...
