MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
Fault Information and Extended Fault Information
"Fault Information" Contents
0100h Address out of range
0200h Group number 0 not
permitted
0A00h Failed to send Global
Control request
FF00h Module not initialized
ProSoft Technology, Inc.
July 8, 2011
"Extended Fault Information" Contents
-
-
0A00h Incorrect operation mode (Clear/Operate Only)
0150h Invalid Freeze Group (Group is not initiated to be
Freeze Group)
0250h Invalid Sync Group (Group is not initiated to be
Sync Group)
0350h Incorrect Control Command
0450h No Sync -/ or Freeze groups enabled in Master
configuration
-
